Menu Key
Press the Menu key to display a grid of shortcut icons for installed measurement modes and
user selected menus and setup files.
Figure 2-2
shows the Menu key screen with shortcut icons for the installed measurement
modes. Touch one of the icons in the top two rows to change modes. These icons are
preinstalled and can not be moved or deleted.
Figure 2-2.
Menu Key Screen, Icons for Installed Measurements and Shortcuts
The display of the Menu screen will vary depending on Spectrum Master model,
Note
firmware version, and installed options.
Figure 2-3
shows the Menu key screen with shortcut icons for the installed measurement
modes and four rows of user-defined shortcuts to menus and setup files.
