General Information
1-6

Standard Accessories

The Anritsu Spectrum Master includes a one year warranty which includes: battery,
firmware, software, and Certificate of Calibration and Conformance.
The Spectrum Master Technical Data Sheet (P/N: 11410-00597) contains a list and
description of standard accessories.
When using the Automotive Cigarette Lighter Adapter, always verify that the
supply is rated for a minimum of 60 Watts at 12 VDC, and that the socket is clear
Caution
of any dirt or debris. If the adapter plug becomes hot to the touch during operation,
then discontinue use immediately.
1-7

Optional Accessories

The Spectrum Master Technical Data Sheet (P/N: 11410-00597) also contains a list and
description of available optional accessories.
The data sheet is provided with the instrument and also available on the Anritsu web site:
http://www.anritsu.com.
1-8

Additional Documents

This user guide is specific to the Spectrum Master and includes a general description about
the instrument. For information about Spectrum Analysis, Interference Analysis,
Tracking Generator, Channel Scanner, AM/FM/PM Analysis, Power Meter and Master
Software Tools, refer to the individual Guides listed in
1-9

General Description

The Spectrum Master MS2711E is an integrated multi-functional test instrument that
eliminate the need to carry and learn multiple test sets. The Spectrum Master can be
configured to include: spectrum analyzer, interference analyzer with interference mapping
capabilities, tracking generator, channel scanner, power meter, high accuracy power meter,
and an AM/FM/PM analyzer. A GPS receiver can be added to the MS2711E Spectrum Master
model.
The bright 8.4 inch TFT color display provides easy viewing in a variety of lighting conditions.
The MS2711E model is equipped with a Li-Ion battery delivering more than three hours of
battery life.
The combination of a touch screen and keypad enables users to navigate menus with the
touch screen and enter numbers with the keypad.
Spectrum Master User Guide PN: 10580-00328 Rev. E

1-6 Standard Accessories

Appendix A, "Measurement Guides".
