Copy Menu - Anritsu Spectrum Master MS2711E User Manual

4-4 File Menu

Copy Menu

Key Sequence: File > Copy
Copy
Sort By
Name Type Date
Sort Order
Asc Desc
File Type
ALL
Refresh
Directories
Scroll
Scr Dst
Select
or
De-Select
Copy
Figure 4-12. Copy Menu
4-12
This menu and dialog box is used to copy folders and files. Select folders or
files with the Up/Down keys, the rotary knob or the touch screen.
on page 4-4 shows the Copy dialog box with two JPG images and one
folder (including the folder's contents) selected and ready to be copied to
the USB flash drive. Highlight a folder and press Enter to view the contents.
Sort By: Press this submenu key to sort file and folder lists by name, by
type of file, or by the date that the file was saved.
Sort Order: Displays the folder or file in ascending or descending order
based on the selection in the Sort By key.
File Type: Press this submenu key to select what type of file to view for
copying. The options are: ALL, Measurement, Setup, or JPG. The file type
can be changed with the Up/Down keys, the rotary knob, or the touch
screen. Press Enter to make the selection.
Refresh Directories: Press this key to update the display.
Scroll Scr Dst: Press this submenu key to use the scroll function in the
Source Folder (Scr - top panel) or Destination Folder (Dst - bottom panel).
See Figure 4-3.
Select or De-Select: Use this key to select or deselect the file(s) or
folder(s) to be copied. When selected, a file or folder will be outlined in blue,
see Figure 4-3.
Copy: Copies the files or folders selected in the top window to the
destination selected in the bottom window. A dialog box will display showing
when the copying is complete. If a file with the same name exists in the
destination folder a warning box will display to allow file overwrite or to
cancel.
PN: 10580-00328 Rev. E
File Management
Figure 4-3
Spectrum Master User Guide
