GENERAL INFORMATION
ALL TYPE
BATTERY NEGATIVE (–)
CABLE
BATTERY NEGATIVE (–)
TERMINAL
ALL TYPE
MAIN WIRE HARNESS
BATTERY NEGATIVE (–)
TERMINAL
1-34
FUEL PUMP 3P (Black) CONNECTOR
STARTER RELAY SWITCH
4P (Red) CONNECTOR
FUEL PUMP 3P (Black) CONNECTOR
REAR BRAKE LIGHT SWITCH
2P (Black) CONNECTOR
REAR BRAKE LIGHT SWITCH
2P (Black) CONNECTOR
OPTIONAL 6P CONNECTOR
BATTERY NEGATIVE (+)
TERMINAL
DLC
OPTIONAL 6P
CONNECTOR
REAR WHEEL SPEED SENSOR
2P (Gray) CONNECTOR
(CBR650FA, CB650FA only)
