Honda CBR540F Owner's Manual
This manual should be considered a permanent part of the motorcycle
and should remain with the motorcycle when it is resold.
This publication includes the latest production information available
before printing. Honda Motor Co., Ltd. reserves the right to make
changes at any time without notice and without incurring any obligation.
No part of this publication may be reproduced without written
permission.
The vehicle pictured in this owner's manual may not match your actual
vehicle.
© 2014 Honda Motor Co., Ltd.
http://www.motorcycle.in.th
