LUBRICATION & SEAL POINTS
ENGINE
MATERIAL
Sealant (TB1207B
manufactured by ThreeBond
or an equivalent)
Sealant (TB5211C
manufactured by ThreeBond,
KE45 manufactured by Shin-
Etsu Silicone or an
equivalent)
Engine oil
(without molybdenum
additives)
Multi-purpose grease
Molybdenum oil solution (a
mixture of engine oil and
molybdenum disulfide grease
in a ratio of 1:1)
Heat-resistant locking agent
(TB1360 or TB2440B
manufactured by ThreeBond,
DL-201 manufactured by
LOCTITE or equivalent)
LOCATION
Oil pan mating surface
Right crankcase cover mating area (cover side)
Crankcase mating area (right side of the case)
CKP sensor wire grommet seating surface
Left crankcase cover mating area (cover side)
Crankcase mating area (left side of the case)
Lower crankcase mating surface
EOP switch threads
Cylinder head cover packing semi-circular area
Engine oil filter cartridge threads and packing
Fuel injector seal ring
Engine oil strainer seal ring
Valve stem seal fitting area
Clutch disc and plate entire surface
Starter one-way clutch contacting surface
Shift fork guide area and guide pin
Shift fork shaft outer surface
Piston ring entire surface
Piston ring grooves
Piston pin hole inner surface
Piston sliding surface
Cylinder inner surface
Each gear teeth and rotating surface
Each bearing rotating area
Each O-ring
Other rotating and sliding areas
Timing hole cap threads
Each oil seal lips
Water pump shaft and thrust washer sliding area
Valve stem sliding surface
Valve lifter sliding surface
Camshaft journals, lobes and thrust surfaces
Clutch outer guide entire surface
Clutch outer gear, friction spring and clutch outer sliding
surface
Starter reduction gear sliding surface
Starter idle gear shaft outer surface
Transmission rotating gear inner surface
Transmission gear bushing entire surface (M5, C2)
Transmission gear spline bushing outer surface (M6,
C3, C4)
Transmission gear inner spline surface (C5, C6)
Transmission gear shifter groove (M3, M4, C5, C6)
Transmission needle bearing rotating area (C1)
Crankshaft main journal bearing sliding surface
Crankshaft thrust surfaces
Crankpin bearing sliding surface
Connecting rod small end inner surface
Piston pin outer surface
Shift drum center socket bolt threads
GENERAL INFORMATION
REMARKS
See page 9-7
See page 11-5
See page 11-5
See page 12-4
See page 12-4
See page 13-5
See page 21-14
See page 10-5
Except IACV and water
passage O-rings
Coating width: 6.5 mm (0.26 in)
from tip
