HYDRAULIC BRAKE
ITEM
Brake caliper bleed valve
Front master cylinder reservoir cap
screw
Rear brake reservoir cap screw
Brake caliper pad pin
Rear brake caliper bolt
Front master cylinder holder bolt
Brake hose oil bolt
Front brake lever pivot bolt
Front brake lever pivot nut
Front brake light switch screw
Rider footpeg bracket bolt
Rear master cylinder mounting bolt
Front brake caliper mounting bolt
Front brake caliper pin bolt A
Rear master cylinder hose joint screw
Rear master cylinder push rod joint nut
Rear brake caliper pin bolt
ANTI-LOCK BRAKE SYSTEM (CBR650FA, CB650FA)
ITEM
Brake pipe joint nut
LIGHTS/METERS/SWITCHES
ITEM
Turn signal light lens screw
Front turn signal light mounting nut
(CBR650F/FA)
Front turn signal light mounting screw
(CB650F/FA)
Rear turn signal light mounting screw
License light lens screw
Combination meter mounting screw
EOP switch
EOP switch terminal screw
Ignition switch mounting bolt
Neutral switch
Sidestand switch mounting bolt
THREAD
Q'TY
DIA. (mm) N·m (kgf·m, lbf·ft)
3 8
2 4
2 4
3 10
1 8
2 6
5 10
1 6
1 6
1 4
4 8
2 6
4 8
2 8
1 4
1 8
1 12
THREAD
Q'TY
DIA. (mm) N·m (kgf·m, lbf·ft)
4 10
THREAD
Q'TY
DIA. (mm) N·m (kgf·m, lbf·ft)
4 3
2 6
2 6
2 6
2 4
3 5
1 PT 1/8
1 4
2 8
1 10
1 6
GENERAL INFORMATION
TORQUE
5.4 (0.6, 4.0)
1.5 (0.2, 1.1)
1.5 (0.2, 1.1)
17 (1.7, 13)
22 (2.2, 16) ALOC bolt; replace with a new
one.
12 (1.2, 9)
34 (3.5, 25)
1.0 (0.1, 0.7)
5.9 (0.6, 4.4)
1.2 (0.1, 0.9)
37 (3.8, 27)
12 (1.2, 9)
30 (3.1, 22) ALOC bolt; replace with a new
one.
22 (2.2, 16) Apply locking agent to the
threads.
1.5 (0.2, 1.1) Apply locking agent to the
threads.
17 (1.7, 13)
27 (2.8, 20)
TORQUE
14 (1.4, 10) Apply brake fluid to the
threads.
TORQUE
1.5 (0.2, 1.1)
10 (1.0, 7)
2.5 (0.3, 1.8)
2.5 (0.3, 1.8)
1.0 (0.1, 0.7)
1.0 (0.1, 0.7)
12 (1.2, 9) Apply liquid sealant to the
threads.
2.0 (0.2, 1.5)
24 (2.4, 18) One-way bolt; replace with a
new one.
12 (1.2, 9)
10 (1.0, 7) ALOC bolt; replace with a new
one.
REMARKS
REMARKS
REMARKS
1-15
