GENERAL INFORMATION
DRIVE TRAIN Clutch system
Clutch operation system
Transmission
Primary reduction
Final reduction
Gear ratio
Gearshift pattern
ELECTRICAL Ignition system
Starting system
Charging system
Regulator/rectifier
Lighting system
PGM-FI SYSTEM SPECIFICATIONS
Engine idle speed
ECT senor resistance (40°C/104°F)
IAT sensor resistance (20°C/68°F)
Fuel injector resistance (20°C/68°F)
O sensor heater resistance (20°C/68°F)
2
IACV resistance (25°C/77°F)

IGNITION SYSTEM SPECIFICATIONS

Spark plug
Spark plug gap
Ignition coil peak voltage
CKP sensor peak voltage
Ignition timing ("F" mark)

ELECTRIC STARTER SPECIFICATION

Starter motor brush length
FUEL SYSTEM SPECIFICATIONS
ITEM
Throttle body identification
number
Throttle grip freeplay
Fuel pressure at idle
Fuel pump flow (at 12 V)
PAIR control solenoid valve resistance (20°C/68°F)
EVAP purge control solenoid valve resistance (20°C/68°F)
(TH model only)
1-6
ITEM
ITEM
ITEM
ITEM
Except TH model
TH model
1st
2nd
3rd
4th
5th
6th
1,250 ± 100 min
CR9EH-9 (NGK), U27FER9 (DENSO)
0.80 – 0.90 mm (0.031 – 0.035 in)
5° BTDC at idle speed
STANDARD
12.0 – 13.0 (0.47 – 0.51)
2 – 6 mm (0.1 – 0.2 in)
343 kPa (3.5 kgf/cm
3
125 cm (4.23 US oz, 4.40 Imp oz) minimum/10 seconds
SPECIFICATION
Multi-plate, wet
Cable operating
Constant mesh, 6 speeds
1.690 (71/42)
2.800 (42/15)
3.071 (43/14)
2.235 (38/17)
1.777 (32/18)
1.520 (38/25)
1.333 (36/27)
1.214 (34/28)
Left foot operated return system
1 - N - 2 - 3 - 4 - 5 - 6
Full transistorized ignition
Electric starter motor
Triple phase output alternator
FET shorted/triple phase full wave
rectification
Battery
SPECIFICATIONS
-1
(rpm)
1.0 – 1.3 kΩ
1 – 4 kΩ
11 – 13 Ω
10 – 40 Ω
110 – 150 Ω
SPECIFICATION
100 V minimum
0.7 V minimum
SERVICE LIMIT
6.5 (0.26)
SPECIFICATIONS
GQ8GA
GQ8GB
2
, 50 psi)
23 – 27 Ω
30 – 34 Ω
Unit: mm (in)
