Setup
Connection Specifications
W
IRING
Max. input voltage
Max. load current
Max. voltage drop
Max. load inductance
Figure 3-40
Output voltage
Max. load current
Figure 3-41
3-58
E
XAMPLES
DigOUT1 "sinks" (analogously valid for DigOUT2 and Compact)
DigOUT1 "source" (analogously valid for DigOUT2 and Compact)
Document ID: rel8003
Edition: May 2018
© 2018 maxon motor. Subject to change without prior notice.
DigOUT "sinks"
+36 VDC
500 mA
0.5 V @ 500 mA
100 mH @ 24 VDC; 500 mA
DigOUT "source"
U = 5.45 V − 0.75 V − (I
Out
≤2 mA
I
Load
EPOS4 Module/Compact 50/5 Hardware Reference
x 2200 Ω)
Load
