BONFIGLIOLI AS Series Manual page 63

1350 Nm
i
n
2
-1
min
AS 55_ 4.55 615
AS 55_ 5.07 552
AS 55_ 5.68 493
AS 55_ 6.42 436
AS 55_ 7.31 383
AS 55_ 8.14 344
AS 55_ 9.13 307
AS 55_ 10.31 272
AS 55_ 11.31 248
AS 55_ 12.6 222
AS 55_ 14.13 198
AS 55_ 15.96 175
AS 55_ 18.31 153
AS 55_ 20.4 137
AS 55_ 22.87 122
AS 55_ 25.84 108
AS 55 D_ 29.8 94
AS 55 D_ 33.2 84
AS 55 D_ 37.2 75
AS 55 D_ 42.1 67
AS 55 D_ 54.9 51
AS 55 D_ 61.2 46
AS 55 D_ 68.6 41
AS 55 D_ 77.5 36
AS 55 D_ 87.0 32
AS 55 D_ 96.9 29
AS 55 D_ 108.6 25.8
AS 55 D_ 122.7 22.8
AS 55 D_ 134.8 20.8
AS 55 D_ 150.2 18.6
AS 55 D_ 168.4 16.6
AS 55 D_ 190.3 14.7
= 2800 min
-1
n
1
M P R
n2 n1 n1
Nm kW N
640 43 2350
640 39 2500
640 35 2500
640 31 2500
900 38 1230
900 34 2240
900 30 2420
900 27 2500
1000 27 1210
1000 24 2250
1000 22 2430
1000 19.3 2500
1100 18.5 1030
1200 18.1 1270
1200 16.2 2280
1200 14.3 2470
1200 12.7 1050
1200 11.4 1300
1200 10.2 1500
1200 9.0 1600
1200 6.9 1500
1200 6.2 1600
1200 5.5 1600
1200 4.9 1600
1200 4.4 1600
1200 3.9 1600
1200 3.5 1600
1200 3.1 1600
1200 2.8 1600
1200 2.5 1600
1200 2.3 1600
1200 2.0 1600
= 1400 min
n
1
R n M
n2 2 n2
-1
N min Nm
6460 308 800
6850 276 800
7300 246 800
7720 218 800
6650 192 1100
7100 172 1100
7600 153 1100
8150 136 1100
7700 124 1100
8250 111 1100
8800 99 1100
9400 88 1100
9150 76 1200
9300 69 1200
9950 61 1200
10700 54 1200
12100 47 1200
12800 42 1200
13500 38 1200
14300 33 1200
15000 26 1200
15000 22.9 1200
15000 20.4 1200
15000 18.1 1200
15000 16.1 1200
15000 14.4 1200
15000 12.9 1200
15000 11.4 1200
15000 10.4 1200
15000 9.3 1200
15000 8.3 1200
15000 7.4 1200
AS 55
-1
P R R
n1 n1 n2
kW N N
27 2500 7890
24 2500 8400
22 2500 8900
19 2500 9450
23 1616 8200
21 2500 8800
18.6 2500 9400
16.4 2500 10100
15.0 2500 10100
13.5 2500 10800
12.0 2500 11500
10.6 2500 12200
10.1 2500 12000
9.1 2500 12800
8.1 2500 13600
7.2 2500 14400
6.4 1600 15000
5.7 1600 15000
5.1 1600 15000
4.5 1600 15000
3.5 1600 15000
3.1 1600 15000
2.8 1600 15000
2.4 1600 15000
2.2 1600 15000
2.0 1600 15000
1.7 1600 15000
1.5 1600 15000
1.4 1600 15000
1.3 1600 15000
1.1 1600 15000
1.0 1600 15000
