BONFIGLIOLI AS Series Manual page 61

800 Nm
i
n
2
-1
min
AS 45_ 4.42 633
AS 45_ 4.89 573
AS 45_ 5.43 516
AS 45_ 6.07 461
AS 45_ 8.14 344
AS 45_ 9.0 311
AS 45_ 10.0 280
AS 45_ 11.18 250
AS 45_ 12.89 217
AS 45_ 14.25 196
AS 45_ 15.83 177
AS 45_ 17.7 158
AS 45_ 19.99 140
AS 45_ 22.09 127
AS 45_ 24.55 114
AS 45_ 27.45 102
AS 45 D_ 31.1 90
AS 45 D_ 34.4 81
AS 45 D_ 38.2 73
AS 45 D_ 42.7 66
AS 45 D_ 45.7 61
AS 45 D_ 50.5 55
AS 45 D_ 56.1 50
AS 45 D_ 62.7 45
AS 45 D_ 76.8 36
AS 45 D_ 84.9 33
AS 45 D_ 94.3 29.7
AS 45 D_ 105.5 26.5
AS 45 D_ 147.2 19.0
AS 45 D_ 162.7 17.2
AS 45 D_ 180.7 15.5
AS 45 D_ 202.1 13.9
= 2800 min
-1
n
1
M P R
n2 n1 n1
Nm kW N
420 29.3 1750
420 26.5 1750
420 23.8 1750
420 21.3 1750
520 19.7 1750
520 17.8 1750
520 16.0 1750
520 14.3 1750
590 14.1 1750
590 12.8 1750
590 11.5 1750
590 10.3 1750
720 11.1 1750
720 10.0 1750
720 9.0 1750
720 8.1 1750
720 7.3 1050
720 6.6 1080
720 6.0 1080
720 5.3 1080
720 5.0 1080
720 4.5 1080
720 4.1 1080
720 3.6 1080
720 3.0 1080
720 2.7 1080
720 2.4 1080
720 2.2 1080
720 1.5 1080
720 1.4 1080
720 1.3 1080
720 1.1 1080
= 1400 min
n
1
R n M
n2 2 n2
-1
N min Nm
3500 317 520
3700 286 520
3900 258 520
4100 231 520
4100 172 650
4300 156 650
4600 140 650
4900 125 650
4700 109 650
5000 98 650
5300 88 650
5600 79 650
5200 70 720
5500 63 720
5800 57 720
6200 51 720
7150 45 720
7500 41 720
7900 37 720
8300 33 720
8350 31 720
8800 27.7 720
9200 25.0 720
9500 22.3 720
9500 18.2 720
9500 16.5 720
9500 14.8 720
9500 13.3 720
9500 9.5 720
9500 8.6 720
9500 7.7 720
9500 6.9 720
AS 45
-1
P R R
n1 n1 n2
kW N N
18.1 1750 4250
16.4 1750 4500
14.8 1750 4800
13.2 1750 5050
12.3 1750 5000
11.1 1750 5300
10.0 1750 5600
9.0 1750 6000
7.8 1750 6200
7.0 1750 6500
6.3 1750 6900
5.7 1750 7300
5.6 1750 7200
5.0 1750 7500
4.5 1750 8000
4.0 1750 8400
3.7 1080 9400
3.3 1080 9500
3.0 1080 9500
2.7 1080 9500
2.5 1080 9500
2.3 1080 9500
2.0 1080 9500
1.8 1080 9500
1.5 1080 9500
1.3 1080 9500
1.2 1080 9500
1.1 1080 9500
0.77 1080 9500
0.70 1080 9500
0.63 1080 9500
0.56 1080 9500
