BONFIGLIOLI AS Series Manual page 57

100 Nm
i
n
2
-1
min
AS 20_ 5.49 510
AS 20_ 6.46 433
AS 20_ 7.75 361
AS 20_ 8.57 327
AS 20_ 9.92 282
AS 20_ 11.67 240
AS 20_ 14 200
AS 20_ 15.48 181
AS 20_ 18.01 155
AS 20_ 21.19 132
AS 20_ 25.43 110
AS 20_ 28.13 100
AS 20_ 31.71 88
AS 20_ 37.31 75
AS 20_ 44.77 63
AS 20_ 49.52 57
AS 20 D_ 58.1 48
AS 20 D_ 64.3 44
AS 20 D_ 69.2 40
AS 20 D_ 81.4 34
AS 20 D_ 97.7 28.7
AS 20 D_ 108.1 25.9
AS 20 D_ 120.1 23.3
AS 20 D_ 141.3 19.8
AS 20 D_ 169.5 16.5
AS 20 D_ 187.5 14.9
AS 20_ 5.49 164
AS 20_ 6.46 139
AS 20_ 7.75 116
AS 20_ 8.57 105
AS 20_ 9.92 91
AS 20_ 11.67 77
AS 20_ 14.0 64
AS 20_ 15.48 58
AS 20_ 18.01 50
AS 20_ 21.19 42
AS 20_ 25.43 35
AS 20_ 28.13 32
AS 20_ 31.71 28.4
AS 20_ 37.31 24.1
AS 20_ 44.77 20.1
AS 20_ 49.52 18.2
AS 20 D_ 58.1 15.5
AS 20 D_ 64.3 14.0
AS 20 D_ 69.2 13.0
AS 20 D_ 81.4 11.1
AS 20 D_ 97.7 9.2
AS 20 D_ 108.1 8.3
AS 20 D_ 120.1 7.5
AS 20 D_ 141.3 6.4
AS 20 D_ 169.5 5.3
AS 20 D_ 187.5 4.8
= 2800 min
-1
n
1
M P R
n2 n1 n1
Nm kW N
50 2.8 600
50 2.4 600
50 2.0 600
50 1.8 600
55 1.7 600
55 1.5 600
55 1.2 600
55 1.1 600
80 1.4 600
80 1.2 600
80 0.97 600
80 0.88 600
80 0.78 600
80 0.66 600
80 0.55 600
80 0.50 600
90 0.49 330
90 0.44 330
90 0.41 330
90 0.35 330
90 0.29 330
90 0.26 330
90 0.24 330
90 0.20 330
90 0.17 330
90 0.15 330
= 900 min
-1
n
1
90 1.6 600
90 1.4 600
90 1.2 600
90 1.0 600
90 0.90 600
90 0.76 600
90 0.64 600
90 0.58 600
90 0.50 600
90 0.42 600
90 0.35 600
90 0.32 600
90 0.28 600
90 0.24 600
90 0.20 600
90 0.18 600
100 0.17 330
100 0.16 330
100 0.15 330
100 0.12 330
100 0.10 330
100 0.09 330
100 0.08 330
100 0.07 330
100 0.06 330
100 0.05 330
= 1400 min
n
1
R n M
n2 2 n2
-1
N min Nm
730 255 60
800 217 60
890 181 60
940 163 60
940 141 65
1030 120 65
1140 100 65
1200 90 65
1040 78 80
1150 66 80
1280 55 80
1350 50 80
1390 44 80
1530 38 80
1680 31 80
1770 28.3 80
1810 24.1 90
1910 21.8 90
1930 20.2 90
2100 17.2 90
2300 14.3 90
2410 13.0 90
2470 11.7 90
2680 9.9 90
2800 8.3 90
2800 7.5 90
= 500 min
n
1
920 91 100
1030 77 100
1160 65 100
1240 58 100
1290 50 100
1420 43 100
1580 36 100
1670 32 100
1740 27.8 100
1900 23.6 100
2090 19.7 100
2190 17.8 100
2270 15.8 100
2460 13.4 100
2680 11.2 100
2800 10.1 100
2800 8.6 100
2800 7.8 100
2800 7.2 100
2800 6.1 100
2800 5.1 100
2800 4.6 100
2800 4.2 100
2800 3.5 100
2800 2.9 100
2800 2.7 100
AS 20
-1
P R R
n1 n1 n2
kW N N
1.7 600 950
1.4 600 1040
1.2 600 1150
1.1 600 1210
1.0 600 1220
0.86 600 1340
0.72 600 1470
0.65 600 1540
0.68 600 1490
0.58 600 1620
0.48 600 1780
0.44 600 1880
0.39 600 1940
0.33 600 2100
0.28 600 2290
0.25 600 2400
0.24 330 2476
0.22 330 2595
0.21 330 2632
0.17 330 2800
0.15 330 2800
0.13 330 2800
0.12 330 2800
0.10 330 2800
0.08 330 2800
0.08 330 2800
-1
1.0 600 1200
0.85 600 1340
0.71 600 1490
0.64 600 1580
0.55 600 1650
0.47 600 1810
0.39 600 2000
0.36 600 2100
0.31 600 2200
0.26 600 2400
0.22 600 2620
0.20 600 2750
0.17 600 2800
0.15 600 2800
0.12 600 2800
0.11 600 2800
0.10 330 2800
0.09 330 2800
0.08 330 2800
0.07 330 2800
0.06 330 2800
0.05 330 2800
0.05 330 2800
0.04 330 2800
0.03 330 2800
0.03 330 2800
