D Inlet Pressure
Enter the valve inlet pressure (INLET_PRESSURE
[83.7]).
D Outlet Pressure
Enter the valve outlet pressure (OUTLET_PRESSURE
in psig, kPa, Bar, in Hg or in H
[83.8])

Trim

(TB > Detailed Setup > Act and Valve > Trim)
D Seat Type
Enter the valve seat type (SEAT_TYPE [84.1]).
D Leak Class
Enter the valve leak class (LEAK_CLASS [84.2]).
D Port Diameter
Enter the valve port diameter (PORT_DIAMETER
[84.3]) in inches or mm.
D Port Type
Enter the valve port type (PORT_TYPE [84.4]).
D Flow Direction
Enter the flow direction (FLOW_DIRECTION [84.5])
through the valve.
D Push Down To
Enter the effect on valve movement when the stem is
moved down (PUSH_DOWN_TO [84.6]).
D Flow Tends To
Enter the effect on valve travel with increasing flow
(FLOW_TENDS_TO [84.7]).
D Unbalanced Area
Enter the valve unbalanced area
(UNBALANCED_AREA [84.8]) in in
March 2006

Actuator

(TB > Detailed Setup > Act and Valve > Actuator)
Enter the manufacturer's identification number
(ACT_MAN_ID [22]) of the actuator on which the
O.
instrument is mounted. Select from the drop-down list
2
or enter the manufacturer's identification number as
defined by the Fieldbus Foundation. For Fisher, the
manufacturer ID hex value is 005100.
Enter the type number for the actuator
(ACT_MODEL_NUM [23]) on which the instrument is
mounted.
Enter the serial number (ACT_SN [24]) for the
actuator on which the instrument is mounted.
Enter the size of the actuator (ACTUATOR_SIZE
[85.1]) on which the instrument is mounted.
Sets actuator action to be performed upon loss of
actuator air pressure (ACT_FAIL_ACTION [21]).
Select the feedback connection (FEEDBACK_CONN
[42.4]), Rotary All, SStem - Roller or SStem -
Standard. For rotary valves, enter Rotary - All, SStem
- Roller. For sliding-stem valves, if the feedback
linkage consists of a connector arm, adjustment arm,
and feedback arm (similar to figure 5-1), enter SStem -
Standard. If the feedback linkage consists of a roller
that follows a cam (similar to figure 5-2), enter Rotary
All, SStem - Roller.
2 2
or mm .
Transducer Block
D Actuator Manufacturer Id
D Actuator Model Number
D Actuator Serial Number
D Act Size
D Actuator Fail Action
D Feedback Conn
D Tvl Sen Motion
Note
The Travel Sensor Motion is set
automatically by the Setup Wizard, or
during the Auto Calibration procedure.
