Emerson Fisher Fieldvue DVC6030f Instruction Manual page 153

Table 5-31. PID Function Block System Parameters Definitions (Continued)
Label Index
PARAMETER_NAME Number
Output Scale
11
OUT_SCALE
Grant Deny
12
GRANT_DENY
GRANT 12.1
DENY 12.2
Control Options
13
CONTROL_OPTS
Status Options
14
STATUS_OPTS
Input
15
IN
Process Value Filter Time
16
PV_FTIME
Bypass
17
BYPASS
Cascade Input
18
CAS_IN
Setpoint Rate Down
19
SP_RATE_DN
Setpoint Rate UP
20
SP_RATE_UP
Setpoint High Limit
21
SP_HI_LIM
Setpoint Low Limit
22
SP_LO_LIM
March 2006
RO / Block
Range
RW Mode
EU at 100%
EU at 0%t
OOS
Units index
Decimal Point
0: Program
1: Tune
ALL
2: Alarm
3: Local
0: Program
1: Tune
ALL
2: Alarm
3: Local
0: Bypass Enable
1: SP tracks PV in MAN
2: SP tracks PV in ROUT
3: SP tracks PV in LO or
MAN
4: SP tracks RCAS or CAS
in IMAN, LO, MAN or
ROUT
OOS
5: Direct Acting
7: Track Enable
8: Track in Manual
9: Use PV for BKCAL_OUT
10: Act on IR
12: Restrict SP to limits in
Cas and RCas
13: No output limits in MAN
0: IFS (Initiate Fault State)
if BAD IN
1: IFS if BAD CAS_IN
OOS
2: Use Uncertain as Good
5: Target to MAN if BAD IN
Status
ALL
Value
ALL Positive
MAN 1=Off
OOS 2=On
Status
ALL
Value
ALL Positive
ALL Positive
PV Scale +/− 10%, must be
ALL
greater than SP_LO_LIM
PV Scale
ALL +/− 10%, must be less than
SP_HI_LIM
−Continued−
PID Function Block
Initial Value Description
100 Data Type: DS-68
0 The high and low scale values, engineering units
% code, and number of digits to the right of the
2 decimal point associated with OUT.
Data Type: DS-70
Options for controlling access of host computers
All bits: 0
and local control panels to operating, tuning, and
alarm parameters of the block. Not used by the
device.
GRANT: 0=N/A, 1=granted
DENY: 0 = N/A, 1= denied
All bits: 0
Data Type: Bit String
0=disable
All bits: 0
1=enable
Allows you to specify control strategy options.
Data Type: Bit String
0=disable
1=enable
All bits: 0
Allows you to select options for status handling
and processing.
BAD:
NC:
Data Type: DS-65
const
The primary input value of the block.
0
Data Type: Float
The time constant of the first−order PV filter. It is
0
the time, in seconds, required for a 63 percent
change in the IN value.
Data Type: Enum
Used to override the calculation of the block.
0=undefined
When enabled, the SP is sent directly to the
output.
BAD
NC:
Data Type: DS-65
const
The setpoint value from another block.
0
Data Type: Float
Ramp rate for downward SP changes. When the
+ INF
ramp rate is set to zero, the SP is used
immediately. PV per second
Data Type: Float
Ramp rate for upward SP changes. When the
+ INF
ramp rate is set to zero, the SP is used
immediately. PV per second
Data Type: Float
100
The highest SP value allowed.
Data Type: Float
0
The lowest SP value allowed.
5
5-87
