DVC6000f Series

Scope of Manual

This instruction manual includes specifications,
installation, operating, and maintenance information
for the DVC6000f Series digital valve controllers. The
manual describes the functionality of the following
R
FIELDVUE fieldbus instruments:
1
Revision Device
(Firmware) Type
1.3, 1.4 4601
1. Device descriptions can be downloaded from the internet at www.fieldvue.com.
This manual describes device setup using the Model
375 Field Communicator. For information on using
AMS ValveLink R Software with the instrument, refer to
the appropriate user guide or help.
No person may install, operate, or maintain a
DVC6000f Series digital valve controller without first D
being fully trained and qualified in valve, actuator, and
accessory installation, operation and maintenance,
and D carefully reading and understanding the
contents of this manual. If you have any questions
concerning these instructions, contact your Emerson
Process Managment
t
proceeding.
Note
Neither Emerson
Management, Fisher
affiliated entities assumes
responsibility for the selection, use or
maintenance of any product.
Responsibility for the selection, use,
or maintenance of any product
remains with the purchaser and
end-user.

Instrument Description

DVC6000f Series digital valve controllers for
F
fieldbus are interoperable,
OUNDATION
t
communicating, microprocessor-based,
digital-to-pneumatic instruments. In addition to the
primary function of converting a digital input signal to a
pneumatic output, the DVC6000f Series digital valve
F
controller, using
OUNDATION
communications protocol, gives easy access to
information critical to process operation as well as
process control. This can be done using a DeltaVt
1-2
Device
DD Compatibility
Revision
2.0 or later;
1
4.0 or later recommended
sales office before
R
, Emerson Process
R , nor any of their
fieldbus
(1)
W9132-1
Figure 1-1. Type DVC6010f Digital Valve Controller
Mounted on Type 585C Piston Actuator
console, another
console, or with AMS ValveLink Software.
DVC6000f Series digital valve controllers can be
mounted on single or double-acting sliding-stem
actuators, as shown in figure 1-1, or on rotary
actuators, as shown in figure 1-2. DVC6000f Series
digital valve controllers mount on most Fisher and
other manufacturers' rotary and sliding-stem
actuators.
DVC6000f Series digital valve controllers are available
with several selections of control and diagnostic
capability. Control selections include:
D Standard Control (SC)— Digital valve
controllers with Standard Control have the AO, PID,
ISEL, OS, AI, MAI, DO, and four DI function blocks in
addition to the resource and transducer blocks.
D Fieldbus Control (FC)—Digital valve controllers
with Fieldbus Control have the AO function block in
addition to the resource and transducer blocks.
D Fieldbus Logic (FL)—Digital valve controllers
with Fieldbus Logic have the DO, and four DI function
blocks, in addition to the resource and transducer
block.
The diagnostic capabilities include:
D Performance Diagnostics (PD)
D Advanced Diagnostics (AD)
D Fieldbus Diagnostics (FD)
F
fieldbus system
OUNDATION
