Label
PARAMETER_NAME
INST_ALERTS_ACTIVE
Elect Active
ELECT_ACTIVE
Sensor Active
SENSOR_ACTIVE
Enviro Active
ENVIRO_ACTIVE
Tvl Active
TRAVEL_ACTIVE
Prox Active
PROX_ACTIVE
Tvl History Active
TVL_HISTORY_ACTIVE
Performance Active
PERF_ACTIVE
PD Event Active
PD_EVENT_ACTIVE
March 2006
Table 5-13. Transducer Block Parameter Definitions (Continued)
Index RO /
Mode Range
Number RW
74
0: Drive Current
1: Drive Signal
2: Memory Failure −
Pending
(1)
74.1 RO ALL 3: Static Memory
4: Processor
5: I/O Processor
6: Output Block Timeout
7: Block Set to Defaults
0: Travel Sensor
1: Port A Pressure
Sensor
2: Port B Pressure
(1)
74.2 RO ALL
Sensor
3: Supply Pressure
Sensor
4: Temperature Sensor
0: Supply Pressure High
1: Supply Pressure Low
(1)
74.3 RO ALL
2: Temperature High
3: Temperature Low
0: Travel Deviation
1: Travel Limit High High
(1)
74.4 RO ALL 2: Travel Limit Low Low
3: Travel Limit High
4: Travel Limit Low
0: Travel Open
1: Travel Closed
2: Proximity High High
(1)
74.5 RO N/A
3: Proximity High
4: Proximity Low
5: Proximity Low Low
0: Cycle Counter
(1)
74.6 RO ALL
1: Travel Accumulator
0: Performance Critical
1: Performance
(1) Reduced
74.7 RO ALL
2: Performance
Information
0: High I/P Drive Signal
1: Low I/P Drive Signal
2: High Air Mass Flow
3: Large Travel
Deviation
4: Low Supply Pressure
5: High Supply Pressure
6: High Crossover
Pressure
7: Low Crossover
Pressure
8: High I/P Drive Signal
(1) 9: Low I/P Drive Signal
74.8 RO ALL
10: High Air Mass Flow
11: Large Travel
Deviation
12: Low Supply Pressure
13: High Supply
Pressure
14: High Crossover
Pressure
15: Low Crossover
Pressure
16: No Air Mass Flow
Estimate
−Continued−
Transducer Block
Protect
Initial Value
Category
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Electronics Alert status
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Sensor Alert status
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Enviro Alert status
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Travel Alert status
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Proximity Alert status.
Data Type: Bit String
0=inactive
All bits: 0 N/A
1=active
Travel History Alert status
Data Type: Bit String
0=inactive
1=active
All bits: 0 N/A
Performance Diagnostic Alert
status
Data Type: Bit String
0=inactive
1=active
All bits: 0 N/A
Performance Diagnostic event
status.
Description
