DVC6000f Series

Parts Ordering

Whenever corresponding with your Emerson Process
Management sales office about this equipment,
always mention the controller serial number. When
ordering replacement parts, refer to the 11-character
part number of each required part as found in the
following parts list. Parts which do not show part
numbers are not orderable.
Note
Use only genuine Fisher replacement
parts. Components that are not
supplied by Emerson Process
Management should not, under any
circumstances, be used in any Fisher
instrument. Use of components not
supplied by Emerson Process
Management will void your warranty,
might adversely affect the performance
of the valve, and might jeopardize
worker and workplace safety.
Note
Neither Emerson, Emerson Process
Management, Fisher, nor any of their
11 affiliated entities assumes responsibility
for the selection, use, and maintenance
of any product. Responsibility for proper
selection, use, and maintenance of any
product remains with the purchaser and
end-user.
Note
All part numbers are for both
aluminum and stainless steel
constructions, unless otherwise
indicated.
11-2

Parts Kits

Conversion kit 6 listed below provides the parts
required to convert a DVC6010f to a DVC6020f.
Conversion kit 7 provides the parts required to convert
a DVC6020f to a DVC6010f.
Kit Description
1* Elastomer Spare Parts Kit (kit contains parts to
service one digital valve controller)
Standard
Extreme Temperature Option
(fluorosilicone elastomers)
2* Small Hardware Spare Parts Kit (kit contains parts
to service one digital valve controller)
3 Conversion Kit (DVC6010f to DVC6020f or
DVC6015 to DVC6025)
Also see note below
Note
For pipe-away construction, also order pipe-away
bracket kit, item 6.
4 Conversion Kit (DVC6020f to DVC6010f or
DVC6015 to DVC6025)
5 Alignment Pin Kit
[kit contains 15 alignment pins (key 46)]
6 Pipe-Away Bracket Kit (DVC6020) [kit contains
mounting bracket (key 74) and O-ring (key 75)]
Standard
Extreme Temperature option
(fluorosilicone elastomers)
7* Seal Screen Kit [kit contains 25 seal screens
(key 231) and 25 O-rings (key 39)]
Standard
Extreme Temperature option
(fluorosilicone elastomers)
8 Terminal Box Kit,
Aluminum
Standard
Extreme Temperature option
(fluorosilicone elastomers)
Stainless Steel
Standard
Extreme Temperature option
(fluorosilicone elastomers)
9 I/P Converter Kit
Standard
For Extreme Temperature option
(fluorosilicone elastomers)
10 Vent with extension
For a DVC6020f replacing a DVC5020f
on an existing mounting
11 Adjustment Arm Kit
(includes washer, nut and adjustment arm)
* Recommended spare
Part Number
19B5402X012
19B5402X022
19B5403X012
19B5405X012
14B5072X112
14B5072X092
19B5404X012
19B5404X022
14B5072X152
14B5072X182
GE22787X012
GE22788X012
GE22789X012
GE22790X012
38B6041X052
38B6041X062
19B3407X012
14B5072X132
March 2006
