Additionally, the instrument can be ordered with three different electrical and pneumatic configurations. Table 1
shows the available configurations and figure 2 shows where the electrical conduit entries and pneumatic ports are
located on the instrument.
Table 1. Electrical and Pneumatic Configurations
Electrical Conduit Entry Size
Imperial
Metric
Metric/Imperial
Figure 2. Electrical and Pneumatic Configuration

Valve/Actuator Mounting

If ordered as part of a control valve assembly, the factory will mount the digital valve controller on the actuator and
calibrate the instrument. If you purchased the digital valve controller separately, you will need a mounting kit. The
4
Pneumatic Port Size
1/2 NPT
M20
M20
LEFT ELECTRICAL
CONDUIT ENTRY
BOTTOM LEFT AND RIGHT
ELECTRICAL CONDUIT ENTRY
1/4 NPT
G1/4
1/4 NPT
Quick Start Guide
D104766X012
PNEUMATIC
CONDUIT
ENTRIES
