DVC6000f Series

AO Block Parameter List

D Read/Write Capability: RO − Read Only, RW − Read Write
D Mode: The block mode(s) required to write to the parameter
D Double indentation and shaded Index Number indicates sub-parameter
Label
PARAMETER_NAME
Static Revision
ST_REV
Tag Description
TAG_DESC
5
Strategy
STRATEGY
Alert Key
ALERT_KEY
Block Mode
MODE_BLK
TARGET
ACTUAL
PERMITTED
NORMAL
Block Error
BLOCK_ERR
Process Variable
PV
Set Point
SP
Output
OUT
5-72
Table 5-24. Analog Output Function Block Parameter Definitions
Index RO / Block
Number RW Mode
1 RO N/A 0 to 65535
2 RW ALL 7 bit ASCII
3 RW ALL 0 to 65535
4 RW ALL 1 to 255
5
OOS
MAN
5.1 RW ALL AUTO
AUTO-CAS
AUTO-RCAS
5.2 RO ALL
OOS+MAN+AUTO+
5.3 RW ALL
CAS+RCAS
5.4 RW ALL
1: Block Configuration
Error
3: Simulate Active
4: Local Override
5: Device Fault State
6 RO N/A Set
7: Input Failure/Bad PV
status
8: Output Failure
14: Power-up
15: Out-of-Service
PV Status set equal
7 RO N/A
to READBACK status
OOS
8 MAN PV_SCALE +/− 10%
AUTO
MAN
9 IMAN
OUT_SCALE +/− 10%
OOS
Initial
Range
Value
Data Type: Unsigned16
The revision level of the static data associated
0 with the function block. The revision value will be
incremented each time a static parameter value in
the block is changed.
Data Type: Octet String
Spaces The user description of the intended application of
the block.
Data Type: Unsigned16
The strategy field can be used to identify grouping
0
of blocks. This data is not checked or processed
by the block.
Data Type: Unsigned8
The identification number of the plant unit. This
0
information may be used in the host for sorting
alarms, etc.
OOS until
Data Type: DS-69
block is
Valid Bits: 7: OOS, 6: IMAN, 5: LO, 4: MAN, 3:
configured,
AUTO, 2: CAS, 1: RCAS
then last valid
The actual, target, permitted, and normal modes
target
of the block.
OOS
OOS+MAN+
AUTO+
CAS+RCAS
AUTO
Data Type: Bit String
0=inactive
1=active
This parameter reflects the error status
Dynamic
associated with the hardware or software
components associated with a block. It is a bit
string, so that multiple errors may be shown. See
table 5-23.
Data Type: DS-65
The process variable used in block execution.
Dynamic This value is converted from READBACK to show
the actuator position in the same units as the
setpoint value.
Data Type: DS-65
The SP of the analog block. Can be derived from
CAS_IN, RCAS_IN in normal modes, or can track
Dynamic PV in MAN or LO modes. IO_OPTS is used to
determine value of SP in MAN or LO. If no
IO_OPTS for SP tracking are set, SP will freeze
when mode changes from CAS or RCAS.
Data Type: DS-65
The primary value and status calculated by the
Dynamic
block in Auto mode. OUT may be set manually in
Man mode.
−Continued−
Description
Target: The requested block mode
Actual: The current mode of the block
(Note: Bit 6 (IMAN) is valid for ACTUAL only)
Permitted: Allowed modes for Target
Normal: Most common mode for Target
