DOUBLE-ACTING
APPLY LUB, SEALANT
NOTE:
1
FOR SINGLE-ACTING DIRECT, OUTPUT B IS PLUGGED.
2
FOR SINGLE-ACTING REVERSE, OUTPUT A IS PLUGGED.
48B7710-G SHT 2 / DOC
Figure 11-8. Typical DVC6000f Series Digital Valve Controller Gauge Configuration
March 2006
1
SINGLE-ACTING DIRECT
Parts
2
SINGLE-ACTING REVERSE
11-15
11
