Emerson Fisher Fieldvue DVC6030f Instruction Manual page 310

DVC6000f Series
Key Description
Relay
24 Relay Assembly, includes shroud, relay seal,
and mounting screws
Standard
Double-acting and single-acting direct
Single-acting reverse
Double-acting and single-acting
direct (low bleed)
Extreme Temperature option
(fluorosilicone elastomers)
Double-acting and single-acting direct
Single-acting reverse
Terminal Box
4 Terminal Box Cap,
Aluminum
Stainless Steel
(1,8)
34* O-ring
(1,8)
36* O-ring
44 Wire Retainer, pl stl
58 Set Screw, hex socket, SST
62 Pipe Plug, hex hd,
Aluminum
Stainless Steel
72 Cap Screw, hex socket, SST
164 Terminal Box Assembly
268 FIELDBUS Label
PWB Assembly
Note
Contact your Emerson Process
11
Management sales office for PWB
Assembly FS Numbers.
50* PWB Assembly
Standard Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance DIagnostic
Fieldbus Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Fieldbus Logic
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
11-4
Part Number
38B5786X052
38B5786X062
38B5786X072
38B5786X032
38B5786X042
38B7714X012
GB0108X0012
(2)
(6 req'd) (not shown)
(2)
1H5137X0012
1H5137X0032
(2)
(8)
Key Description
Pressure Gauges, Pipe Plugs, or Tire
Valve Assemblies
47* Pressure Gauge, nickel-plated brass case, brass connection
Double-acting (3 req'd); Single-acting (2 req'd)
PSI/MPA Gauge Scale
To 60 PSI, 0.4 MPa
To 160 PSI, 1.1 MPa
PSI/bar Gauge Scale
To 60 PSI, 4 bar
To 160 PSI, 11 bar
66 Pipe Plug, hex hd
For Double-acting and single acting direct w/gauges
(none req'd)
For Single-acting reverse w/gauges (1 req'd)
Plated steel
SST
For all units w/o gauges (3 req'd)
Plated steel
SST
67 Tire Valve Assembly (3 req'd)
236 Screen
For single-acting direct units only
Feedback Parts
Common Feedback Parts
80 Cap Screw, hex socket, SST
(2)
81 Square Nut, SST
223* Potentiometer/Bushing Assy
Standard
For DVC6010f, DVC6010fS, DVC6020f,
and DVC6020fS
For DVC6030f and DVC6030fS
For DVC6015 and DVC6025
For DVC6035
Extreme Temperature option (fluorosilicone elastomers)
For DVC6010f, DVC6010fS, DVC6020f and
DVC6020fS
For DVC6030f & DVC6030fS
(2)
163 Plain Washer, SST
* Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
8. Available in the Terminal Box Kit
Part Number
18B7713X042
18B7713X022
18B7713X032
18B7713X012
1D829328982
1D8293X0012
1D829328982
1D8293X0012
1N908899012
18B9610X012
(2)
18B9576X012
17B4030X032
19B6834X012
19B6835X012
GE01028X012
GE01027X012
March 2006
