Emerson Fisher Fieldvue DVC6030f Instruction Manual page 280

DVC6000f Series
PlantWeb Alert
Alert and Category and
(Group) (Default)
Drive Current User Config.
(Electronics) (Failed)
Drive Signal User Config.
(Electronics) (Maintenance)
Processor User Config.
Impaired (Maintenance)
9
(Electronics)
9-8
Table 9-2. Using PlantWeb Alerts
Alert Condition What the Alert is
and (Default) Detecting
Drive Current The difference between the
(Enabled) expected Drive Current and
the actual Drive Current
has exceeded the
configured limit.
Drive Signal The Drive Signal is greater
(Enabled) or less than the expected
maximum or minimum.
Program Memory A failure in the Flash
(Enabled) Memory where the program
is stored.
Static Memory A failure of the FRAM
(Enabled) memory where static
parameters are stored.
Processor A failure of the main
(Enabled) Processor.
I/O Processor A failure of the I/O
(Enabled) Processor.
Effect on Valve /
Instrument
If configured for Self
Test Shutdown, then
the transducer Actual
mode is placed Out of
Service until the
problem is fixed. Out of
Service results in the
instrument output
pressure(s) and
actuator position being
at the Zero Power
Condition.
None − Indicates
reduced performance.
If configured for Self
Test Shutdown, then
the transducer Actual
mode is placed Out of
Service until the
problem is fixed. Out of
Service results in the
instrument output
pressure(s) and
actuator position being
at the Zero Power
Condition.
−Continued−
Recommended
Help
Action
Check I/P The instrument has
module detected that the
difference between the
expected Drive Current
and the actual Drive
Current is greater than
the configured limit
1) Replace the I/P
module
2) Calibrate the device.
If the problem persists,
replace the printed wiring
board (PWB) assembly.
Check The instrument I/P drive
instrument signal necessary to
pneumatics generate the pressure
output from the
instrument is not within
the expected range.
Potential causes include
I/P filter plugged,
instrument pneumatic
relay failure, low supply
pressure, air leaks, or
valve sticking. Test the
control valve assembly
for proper operation.
ValveLink diagnostics
can be used for this
purpose.
Replace PWB An error has been
assembly detected in the printed
wiring board (PWB)
assembly. Replace the
PWB assembly.
March 2006
