DVC6000f Series
View Lists
View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 5-64. MAI Function Block, View 1
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
8 OUT_1
9 OUT_2
10 OUT_3
11 OUT_4
12 OUT_5
13 OUT_6
14 OUT_7
15 OUT_8
5-142
Parameter
Table 5-65. MAI Function Block, View 2
Index
Number
1 ST_REV
Table 5-66. MAI Function Block, View 3
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
8 OUT_1
9 OUT_2
10 OUT_3
11 OUT_4
12 OUT_5
13 OUT_6
14 OUT_7
15 OUT_8
Table 5-67. MAI Function Block, View 4
Index
Number
1 ST_REV
3 STRATEGY
4 ALERT_KEY
7 CHANNEL
Parameter
Parameter
Parameter
