Table 9-2. Using PlantWeb Alerts (Continued)
Alert Condition
What the Alert is
and (Default)
Detecting
Travel Deviation
The difference between
(Enabled)
Setpoint and Travel is
greater than the configured
limits.
Travel Limit Hi Hi
The Travel is greater than
(Disabled)
the configured limit.
Travel Limit Lo Lo
The Travel is lower than the
(Disabled)
configured limit.
Travel Limit Hi
The Travel is greater than
(Disabled)
the configured limit.
Travel Limit Lo
The Travel is lower than the
(Disabled)
configured limit.
Travel Open
The Travel is greater than
(Disabled)
the Open Alert Point
Travel Closed
The Travel is greater than
(Disabled)
the Closed Alert Point
The Travel is within the
Proximity Hi Hi
(Disabled)
configured band of the
configured center point.
Proximity Hi
(Disabled)
Proximity Lo
(Disabled)
Proximity Lo Lo
(Disabled)
Cycle Counter
The number of travel
(Disabled)
reversals has exceeded the
configured limit.
Travel
The accumulated travel has
Accumulator
exceeded the configured
(Disabled)
limit.
Effect on Valve /
Instrument
None − Indicates a
reduced performance
condition.
None
None
None
None
None
None
None
None
None
None
None
None
−Continued−
Recommended
Help
Action
Check valve
The valve travel is not
friction, supply
following setpoint. Check
air, instrument
operation of the valve
tuning
and instrument. Possible
items include; sticking
valve, low supply
pressure, broken
feedback linkage,
instrument pneumatic
components, actuator,
instrument tubing, poor
instrument tuning, etc.
Test the control valve
assembly for proper
operation. AMS
ValveLink Software
diagnostics can be used
for this purpose.
The actual valve position
Check process
has exceeded the
loop
configurable travel limit
Check process
(in %).
loop
Check process
The actual valve position
loop
has exceeded the
configurable travel limit
(in %).
Check process
The actual valve position
loop
has exceeded the
configurable ltravel limit
(in %).
Check process
The actual valve position
loop
is near the full open
position.
Check process
The actual valve position
loop
is near the full closed
position.
Check process
The actual valve position
loop
is near the configured
center point.
Perform periodic
The cycle count limit has
maintenance
been exceeded. Perform
periodic maintenance.
Check packing, linkages,
diaphragms, seals, etc.
Perform periodic
The travel accumulator
maintenance
limit has been exceeded.
Perform periodic
maintenance. Check
packing, linkages,
diaphragms, seals, etc.
March 2006
