OUTPUT B
SUPPLY
WALL MOUNTING
APPLY LUB, SEALANT
NOTES:
1. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
49B2361 SHT 3 / DOC
March 2006
SECTION E-E
OUTPUT A
Figure 11-1. Type DVC6005f Base Unit (continued)
SECTION C-C
OUTPUT A
OUTPUT B
SUPPLY
PIPESTAND MOUNTING
Parts
11
11-7
