DVC6000f Series
Operating Ambient Temperature Limits
−40 to 80_C (−40 to 176_F) for most approved
valve-mounted instruments.
−40 to 125_C (−40 to 257_F) for remote-mounted
1
feedback unit.
−52 to 80_C (−62 to 176_F) for valve-mounted
instruments utilizing the Extreme Temperature
option (fluorosilicone elastomers)

Electrical Classification

Explosion proof, Division 2,
Dust-Ignition proof, Intrinsic Safety,
and FISCO
Explosion proof, Non-incendive,
Dust-Ignition proof, Intrinsic Safety,
and FISCO
APPROVED
Flameproof, Type n, Intrinsic Safety,
ATEX
and FISCO
Flameproof, Type n, Intrinsic Safety,
IECEx
and FISCO
Refer to Special Instructions for Safe Use and
Installation in Hazardous Locations in section 2,
tables 1-3, 1-4, 1-5, and 1-6, and figures D-1, D-2,
D-3, D-4, D-5, D-6, D-7, D-8, D-9 and D-10 for
specific approval information.
Electrical Housing: NEMA 4X, CSA Type 4X, IEC
60529 IP66
Connections
Supply Pressure: 1/4-inch NPT female and
integral pad for mounting 67CFR regulator
Output Pressure: 1/4-inch NPT female
Tubing: 3/8-inch metal, recommended
Vent: 3/8-inch NPT female
Electrical: 1/2-inch NPT female, M20 adapter
optional
Stem Travel
DVC6010f, DVC6015:
0 to 102 mm (4-inches) maximum
0 to 9.5 mm (0.375 inches) minimum
DVC6020f, DVC6025:
0 to 606 mm (23.875 inches) maximum
1. 3-conductor shielded cable, 22 AWG minimum wire size, is recommended for connection between base unit and feedback unit. Pneumatic tubing between base unit output connection
and actuator has been tested to 15 meters (50 feet) maximum without performance degradation.
2. Defined in ISA Standard S51.1.
3
3. Normal m /hour − Normal cubic meters per hour at 0_C and 1.01325 bar, absolute. Scfh − Standard cubic feet per hour at 60_F and 14.7 psia.
4. Values at 1.4 bar (20 psig) based on a single-acting direct relay; values at 5.5 bar (80 psig) based on double-acting relay.
5. Typical value. Not applicable for travels less than 19 mm (0.75 inch) or for shaft rotation less than 60 degrees. Also, not applicable to Type DVC6020f digital valve controllers in long-stroke
applications.
6. The pressure/temperature limits in this manual and any applicable code or standard should not be exceeded.
1-6
Table 1-1. Specifications (continued)
(6)
Shaft Rotation (DVC6020f, DVC6025, DVC6030f
and DVC6035)
0 to 50 degrees minimum
0 to 90 degrees maximum

Mounting

Designed for direct actuator mounting or remote
pipestand or wall mounting. Mounting the
instrument vertically, with the vent at the bottom of
the assembly, or horizontally, with the vent pointing
down, is recommended to allow drainage of
moisture that may be introduced via the instrument
air supply.

Weight

Valve-Mounted Instruments
Aluminum: 3.5 Kg (7.7 lbs)
Stainless Steel: 7.7 Kg (17 lbs)
Remote-Mounted Instruments
DVC6005f Base Unit: 4.1 Kg (9 lbs)
DVC6015 Feedback Unit: 1.3 Kg (2.9 lbs)
DVC6025 Feedback Unit: 1.4 Kg (3.1 lbs)
DVC6035 Feedback Unit: 0.9 Kg (2.0 lbs)

Options

Supply and output pressure gauges or J Tire
J
valves, J Integral mounted filter regulator,
Stainless steel housing, module base and
J
terminal box (valve-mounted instruments only)
Declaration of SEP
Fisher Controls International LLC declares this
product to be in compliance with Article 3 paragraph
3 of the Pressure Equipment Directive (PED) 97 /
23 / EC. It was designed and manufactured in
accordance with Sound Engineering Practice (SEP)
and cannot bear the CE marking related to PED
compliance.
However, the product may bear the CE marking to
indicate compliance with other applicable EC
Directives.
March 2006
