Emerson Fisher Fieldvue DVC6030f Instruction Manual page 309

Key Description
12 PTFE Sleeve Kit [For pot bushing assembly (kit includes
10 sleeves and lubricant)]
DVC6010f and DVC6020f
DVC6030f
13 Spare Module Base Assembly Kit, aluminum
[kit contains module base assy (key 2); drive screws, qty 2,
(key 11); shield/label (key 19); hex socket cap screw, qty 3,
(key 38); self tapping screw, qty 2 (key 49); pipe plug, qty 3
(key 61); retaining ring, qty 3 (key 154); screen (key 236);
and flame arrestors, qty 3 (key 243)]
14 Spare Housing Assembly Kit, aluminum
[kit contains housing (key 1); drive screw, qty 2 (key 11);
shield (key 20); and screen (key 71)]
DVC6010/DVC6020
DVC6030
Remote Mount Kits
Remote Terminal Box Kit
Feedback Unit
DVC6015
DVC6025 long arm
DVC6025 Short Arm
DVC6035
Feedback Unit Termination Strip Kit
Pipestand/Wall Mounting Kit
Parts List
Parts which do not show part numbers are not
orderable as individual parts. In most cases, they are
available in one of the parts kits listed under Parts
Kits.
Note
Parts with footnote numbers shown are
available in parts kits. Also see footnote
information at the bottom of the page.
Key Description
Common Parts
1 Housing
Aluminum
DVC6010f and DVC6020f
DVC6030f
316 SST
DVC6010f and DVC6020f
DVC6030f
March 2006
Part Number Key Description
43 Cover Assembly (includes cover screws)
Aluminum
Standard
GE08726X012 Extreme termperature option
GE08727X012 (fluorosilicone elastomers)
Stainless Steel
Standard
Extreme termperature option
(fluorosilicone elastomers)
48 Nameplate
GE18654X012 52 Vent, plastic
63 Lubricant, lithium grease (not furnished with the instrument)
64 Anti-Seize compound (not furnished with the instrument)
65 Lubricant, silicone sealant (not furnished with the instrument)
GE18652X012 74 Mounting Bracket
GE18653X012 DVC60005 and DVC6020 only
(3)
Std
75* O-Ring, nitrile
GE00418X012
DVC6020 Vent-away only
128 Pipe Plug, pl stl
49B7986X012
DVC6020 Vent-away only
49B7987X012
237 Module Base Seal
49B7987X022
49B7988X012
GE00419X012
Module Base
GE00420X012
The following parts are included in the module
base.
2 Module Base Assembly
12* O-ring, nitrile
16* O-ring, nitrile
24 Relay Module (See Relay listing)
33 Mach Screw, pan hd, SST
38 Cap Screw, hex socket, SST
41 I/P Assembly (See I/P Assembly listing)
154 Retaining Ring
I/P Converter Assembly
23 Cap Screw, hex socket, SST
39* O-ring nitrile
41 I/P Converter
(9)
169 Shroud
210* Boot, nitrile
231* Seal Screen
Part Number
48B7709X012
48B9604X012
GB0113X0012
GB0114X0012
* Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
3. Available in the DVC6010 to DVC6020 Conversion Kit
6. Available in the Pipe-Away Bracket Kit
7. Available in the Seal Screen Kit
9. Available in the I/P Converter Kit
(2)
(6)
or pipe-away
(6)
(6)
(1)
(1)
(1)
(3 req'd)
(2)
(3 req'd)
(2)
(3 req'd)
(2)
(3 req'd)
(2)
(4 req'd)
(1,9)
(9)
(1,9)
(2 req'd)
(1,7,9)
Parts
Part Number
38B9580X012
38B9580X032
38B9580X022
38B9580X042
11
11-3
