H1P 115/130 Axial Piston Single Pumps

Installation drawings

Port Description H1P115/130

54 | © Danfoss | May 2018
M4
2
B
S L4
A
MA
Ports per ISO 11926-1 description
Port Description
System ports A and B
A, B
450 bar, Split flange boss per ISO 6162
System A gauge port
MA
Case pressure port
X3
Case drain port
L4
Servo gauge port
M4
Charge inlet port
S
Please contact Danfoss representative for specific installation drawings.
X3
CCW
Ø31.5 mm; M12 x 1.75; 20 min. full thread depth
Recommended screw in depth 1.5 x thread dia
CW
P005 932
Size 115/130
9
∕ –18; Ø28
16
max clearance dia for fitting
1
1 ∕ –12; Ø41
16
max clearance dia for fitting
5
1 ∕ –12; Ø63
16
max clearance dia for fitting
7
∕ –20; Ø24.5
16
max clearance dia for fitting
5
1 ∕ –12
8
max clearance dia for fitting
BC00000198en-US0901
