Danfoss H1 Series Technical Information page 14

Technical Information
H1P 115/130 Axial Piston Single Pumps
Master Model Code
14 | © Danfoss | May 2018
A B Z D
H1P
M – Overpressure protection type, side "A" / N – Overpressure protection type, side "B"
Pressure limiter and HPRV with bypass, pressure protection type must be the same for side "A" and "B"
1)
L Pressure limiter setting
200 bar [2900 psi]
L20
230 bar [3336 psi]
L23
250 bar [3630 psi]
L25
280 bar [4061 psi]
L28
300 bar [4350 psi]
L30
330 bar [4786 psi]
L33
350 bar [5080 psi]
L35
380 bar [5510 psi]
L38
400 bar [5800 psi]
L40
420 bar [6090 psi]
L42
430 bar [6237 psi]
L43
440 bar [6382 psi]
L44
450 bar [6526 psi]
L45
Overpressure protection type and setting for FDC
150 bar [2175 psi]
F01
150 bar [2175 psi]
F02
150 bar [2175 psi]
F03
150 bar [2175 psi]
F04
High pressure relief valve with bypass, pressure protection type must be the same for side "A" and "B"
1) 2)
K Pressure setting
180 bar [2610 psi]
K18
200 bar [2900 psi]
K20
230 bar [3336 psi]
K23
250 bar [3630 psi]
K25
280 bar [4061 psi]
K28
300 bar [4350 psi]
K30
330 bar [4786 psi]
K33
350 bar [5076 psi]
K35
380 bar [5510 psi]
K38
400 bar [5800 psi]
K40
420 bar [6090 psi]
K42
450 bar [6526 psi]
K45
1)
L, F – with pressure limiter; K – without pressure limiter.
2)
Please contact Danfoss Power Solutions for pressures not shown or for applied pressure above max. working
pressure (see H1P 115/130 Operating Parameters
F E G H J K
on page 6).
M N S T V W
HPRV setting
250 bar [3630 psi]
280 bar [4061 psi]
300 bar [4350 psi]
330 bar [4786 psi]
350 bar [5076 psi]
380 bar [5510 psi]
400 bar [5800 psi]
420 bar [6090 psi]
450 bar [6526 psi]
450 bar [6526 psi]
450 bar [6526 psi]
450 bar [6526 psi]
480 bar [6962 psi]
250 bar [3630 psi]
300 bar [4350 psi]
350 bar [5076 psi]
400 bar [5800 psi]
BC00000198en-US0901
X Y
