Installation Drawings; Frame Size 042 - Danfoss Series 90 Technical Information

Technical Information

Installation Drawings

Frame Size 042

Manual displacement control (MDC), endcap twin ports, option 80
"Y"
Gauge port M2
system pressure B
9/16-18UNF-2B
Port S: Charge
pump inlet
1-1/16-12UN-2B
B
A
"X"
Ports A and B
3/4 – 6000 psi
split flange boss
50.8
per SAE J518
[2.00]
(Code 62)
Approximate
3/8-16UNC-2B
center of gravity
20 [0.787]
minimum full thread
Gauge port M1
system pressure A
9/16-18UNF-2B
Port L1
Case drain
use highest
port as outlet
7/8-14UNF-2B
Manual displacement control handle
Torque applied to control handle shaft
not to exceed 17 Nm [150 lb•in]
R 50.8
Maximum
[R 2.0]
displacement
"B"
Neutral
position
"A"
Maximum [Ø0.265]
displacement
50
Series 90 Axial Piston Pumps
Control MDC, option MA
12.2
(2x)
[0.48]
114.5 [4.51]
Port L2
130
[5.12]
207.8
[8.18]
View "Y"
Gauge port M4
servo pressure
9/16-18UNF-2B
Gauge port M5
56.9
servo pressure
[2.24]
9/16-18UNF-2B
143.5
[5.65]
258
[10.16]
dimensions
12.70
[0.50]
41.67
[1.64]
4.78
[0.188]
R 25.4
[R 1.0]
Ø6,73
2x
520L0603 • Rev 0804 • March 2016
0
9.7
-0.51
[+0.0 ]
[0.38]
[-0.02]
R0.8 max.
[0.03]
Approximate
center
of gravity
Multifunction
valve
Gauge port M3
charge pressure
9/16-18UNF-2B
External charge plug
1 1/16-12 UNF
Multifunction
valve
Ø 6.33
[Ø 0.249]
View "Z"
86 111
[3.39] [4.37]
Rotation
CCW CW
33
[1.30]
Port L2
73
case drain
[2.875]
7/8-14UNF-2B
146
[5.75]
View "X"
Charge pressure
relief valve
P102 040
"W"
