Parameter
Sensitivity
Working range (swash plate angle)
Correlation between signals 1 and 2
1)
Up to duration of 2.5 seconds at 25°C
2)
Signal 1 (nominal) is lower than signal 2 (redundant)

Swash Plate Angle Sensor Connector

DEUTSCH 4-pin connector
4
1
3 2
Connector order numbers
Description
Mating connector DTM06-4S-E004
Wedge lock W4S
Socket contact (16-18 AWG) 0462-201-16141

Interface with ECU

Interface with ECU schematic
V+
Sig1
ECU
Sig2
Gnd
Minimum recommended load resistance is 100 kΩ.
Minimum
70.0 mV/deg
–18°
2) 475 mV
4-Pin Legend:
1. Ground (GND)
2. Output Signal 2 (SIG2) – Secondary (redundant)
3. Output Signal 1 (SIG1) – Primary (nominal)
4. Supply (V+)
E1
0.1uF
E2
340R 340R
5.6 nF
E3
340R 340R
5.6 nF
Typical Maximum
78.0 mV/deg 85.8 mV/deg
0° 18°
500 mV 525 mV
Quantity Order number
1 11105824
1 11084558
2 K02325
VCC
Out 1
Gnd
VCC
Out 2
Gnd
