Technical Information
H1P 115/130 Axial Piston Single Pumps
Installation drawings
58 |
©
Danfoss | May 2018
W
View
239.415 ± 1.0
[9.426 ± 0.039]
System A gauge port "MA"
Port ISO 11926-1 –
/
-18
9
16
∅28.0 max. clearance dia for fitting
Please contact Danfoss representative for specific installation drawings.
X
View
CCW
Rotation
(4x) ∅40.0 ± 0.25
(4x) 80.8 ± 0.25
[1.575 ± 0.01]
[3.18 ± 0.01]
other side screw head space
CW
Rotation
(4x) ∅20.6 + 0.25
– 0.13
[0.811 + 0.01
]
– 0.005
P003 396E
BC00000198en-US0901
