H1P 115/130 Axial Piston Single Pumps
Control Options
© Danfoss | May 2018
Connector
1 2
P003 480
Connector ordering data
Description
Mating connector
Wedge lock
Socket contact (16 and 18 AWG)
Danfoss mating connector kit
Solenoid data
Voltage
Minimum supply voltage
Maximum supply voltage (continuous)
Bi-directional diode cut off voltage
Maximum current
Nominal coil resistance @ 20°C
PWM Range
*
PWM Frequency (preferred)
IP Rating (IEC 60 529) + DIN 40 050
*
PWM signal required for optimum control performance.
Pump output flow direction vs. control signal
Shaft rotation
*
Coil energized
Port A
Port B
Servo port pressurized
*
For coil location see Installation drawings
Quantity
1
1
2
1
12 V
DC
9.5 V
DC
14.6 V
DC
28 V
DC
1050 mA
8.4 Ω
70-200 Hz
100 Hz
IP 67/IP 69K (part 9 with mating connector)
CW
C1 C2
in out
out in
M5 M4
on page 54.
Ordering data
DEUTSCH DT06-2S
DEUTSCH W2S
DEUTSCH 0462-201-16141
K29657
24 V
DC
19 V
DC
29 V
DC
53 V
DC
500 mA
34.5 Ω
CCW
C1 C2
out in
in out
M5 M4
