Technical Information
H1P 115/130 Axial Piston Single Pumps
Master Model Code
© Danfoss | May 2018
A B Z D
H1P
S – Charge pump
26 cm³/rev [1.69 in³/rev]
A
34 cm³/rev [2.07 in³/rev]
L
No charge pump, external charge supply (Align with options: E, T)
N
T – Filtration (Align with option G: End cap selection)
Suction filtration
L
Integral full charge flow filtration with bypass, bypass sensor, long filter length, 11004919
M
Integral full charge flow filtration with bypass, bypass sensor, no filter
N
Remote full charge flow filtration
P
External charge flow filtration (Align with options: N, S)
E
V – Charge pressure relief setting
* 20 bar [290 psi]
20
* 22 bar [319 psi]
22
* 24 bar [348 psi]
24
26 bar [377 psi]
26
28 bar [406 psi]
28
30 bar [435 psi]
30
32 bar [464 psi]
32
34 bar [493 psi]
34
*
Not to be used for NFPE, AC and FDC controls.
W – Special hardware features (Align with options: D and E)
NFPE valve plate
P1
NFPE/FDC/AC valve plate and speed ring on the cylinder block
P2
EDC/FNR/MDC valve plate and speed ring on the cylinder block
P4
EDC/FNR/MDC valve plate
PN
MDC/EDC/FNR valve plate with MDC handle
H1
X – Paint and nametag
Black paint and Danfoss nametag
NNN
F E G H J K M N S T V W
BC00000198en-US0901 | 15
X Y
