Technical Information
H1P 115/130 Axial Piston Single Pumps
Control Options

Swash plate angle sensor for NFPE and AC2 controls

38 | © Danfoss | May 2018
The angle sensor detects the swash plate angle position and direction of rotation from the zero position.
The swash angle sensor works on the AMR sensing technology. Under the saturated magnetic field, the
resistance of the element varies with the magnetic field direction.
The output signal give a linear output voltage for the various magnet positions in the sensing range.
P301 750
Swash plate angle vs. output voltage
Swashplate angle vs. output voltage (calibrated at 50 °C)
Signal 1 (nominal)
Signal 2 (redundant)
-25° -20° -15°

Swash Plate Angle Sensor Parameters (NFPE/AC)

Parameter
Supply voltage range
Supply protection
Supply current
Output current (Signal 1, 2)
Short circuit output current to supply or GND
5
4.5
4
3.5
3
2.5
2
1.5
1
0.5
0
-10° -5° 0° 5°
Swashplate angle
Minimum
4.75 V
–
–
–
1) –
10° 15° 20° 25°
P005 704E
Typical Maximum
5 V 5.25 V
– 28 V
22 mA 25 mA
0.1 mA –
– 7.5 mA
BC00000198en-US0901
