H1P 115/130 Axial Piston Single Pumps
Controls

H1P 115/130 Manual Displacement Control (MDC) with CCO, option M3, M4

62 | © Danfoss | May 2018
Brake gauge port X7
ISO 11926-1 -7/16-20
Control handle shaft
Control Cut Off connector C4:
Deutsch DT04-2P
paint free
Control Cut Off connector C4:
Deutsch DT04-2P
paint free
Control Cut Off connector C4:
Pin Assignment
1 Supply
2 Ground
Please contact Danfoss representative for specific installation drawings.
Shaft
131.9 ±1.2
Case gauge port M14
ISO 11926-1 -7/16-20
4x M6x1-6H thd.
9 min. full thd. depth
paint free
Shaft
52.9±0.8
Mounting flange
70.7±0.8
75.9±0.8
103.3±0.8
102.97 ±0.8
Shaft
Pin
OR 1
2
98.774±1.5
70111500-D12
Assignment
Ground
Supply
