Technical Information
H1P 115/130 Axial Piston Single Pumps
Master Model Code
© Danfoss | May 2018
A B Z D
H1P
H – Mounting (Align with option W – Special hardware features)
ISO 3019-1 flange 152–4 (SAE D)
G
ISO 3019-1 flange 152–4 (SAE D), 4-bolt, with speed sensor
L
J – Input shaft
ISO 3019-1, outer Ø44 mm - 4 (SAE D, 27 teeth splined shaft 16/32 pitch)
G2
ISO 3019-1, outer Ø44 mm - 4 (SAE D, 13 teeth splined shaft 8/16 pitch)
G3
Conical keyed shaft end, code 44-3 (similar to ISO 3019-1), taper 1:8 (key not supplied with pump)
F3
K – Auxiliary mounting pad per ISO 3019-1
None
NN
Flange 82–2, outer Ø16 mm - 4 (SAE C, 13 teeth 16/32 coupling); shipping cover
E5
Flange 82–2, outer Ø19 mm - 4 (SAE A, 11 teeth 16/32 coupling); shipping cover
H1
Flange 82–2, outer Ø16 mm - 4 (SAE A, 9 teeth 16/32 coupling); shipping cover
H2
Flange 101–2, outer Ø22 mm - 4 (SAE B, 13 teeth 16/32 coupling); shipping cover
H3
Flange 152–4, outer Ø44 mm - 4 (SAE D, 13 teeth 8/16 coupling); shipping cover
H4
Flange 101–2, outer Ø25 mm - 4 (SAE B-B, 15 teeth 16/32 coupling); shipping cover
H5
Flange 127–4, outer Ø32 mm - 4 (SAE C, 14 teeth 12/24 coupling); shipping cover
H6
Flange 101–2, outer Ø22 mm - 4 (SAE B, 14 teeth 12/24 coupling); shipping cover
S1
Align with option G – End cap selection.
F E G H J K M N S T V W
BC00000198en-US0901 | 13
X Y
