Danfoss H1 Series Technical Information page 33

Technical Information
H1P 115/130 Axial Piston Single Pumps
Control Options
© Danfoss | May 2018
Pump displacement vs. control current
Forward
100%
a = Forward Threshold
b = Reverse Threshold
N = Neutral Override Current
100%
0
Signal Current (mA(DC
Reverse
Control current
*
Voltage a
12 V 780 mA
24 V 400 mA
*
Factory test current, for fan movement expect higher or lower value.
Connector
1 2
P003 480
Connector ordering data
Description
Mating connector
Wedge lock
Socket contact (16 and 18 AWG)
Danfoss mating connector kit
Description
Maximum current
Nominal coil resistance @ 20 °C [68 °F]
@ 80 °C [176 °F]
Inductance
PWM signal frequency Range
Recommended
H1 FDC control
N b
a
Max Current
))
Avg
P301 443
N
1100 mA
550 mA
Quantity
1
1
2
1
12 V
1800 mA
3.66 Ω
4.52 Ω
33 mH
70 – 200 Hz
*
200 Hz
*
b Pin Config
1300 mA
any order
680 mA
Ordering data
DEUTSCH DT06-2S
DEUTSCH W2S
DEUTSCH 0462-201-16141
K29657
24 V
920 mA
14.20 Ω
17.52 Ω
140 mH
BC00000198en-US0901 | 33
