H1P 115/130 Axial Piston Single Pumps
Dimensions

H1P 115/130 Auxiliary mounting - Option H2 (SAE A, 9 teeth)

Option H2, ISO 3019-1, flange 82-2 (SAE A, 9 teeth)
© Danfoss | May 2018
2x 106.4 ± 0.35
[4.189 ± 0.014]
4x 53.2 ± 0.175
[2.094 ± 0.007]
Thread : M10x1.5-6H THD
Depth : 16.0 [0.63] min.
4x
Specifications
Option
Spline
Maximum torque
For definitions of maximum and rated torque values, refer to H1 Axial Piston Pumps Basic Information,
BC00000057, the section "Shaft Torque Ratings and Spline Lubrication".
C
Caution
Standard pad cover is installed only to retain coupling during shipping. Do not operate pump without an
auxiliary pump or running cover installed.
Mounting flange surface
Flange 82 - 2 per ISO 3019-1
to be paint free
15.3 + 1.0
[0.602 + 0.039
R 0.8 max.
[0.031]
O-ring seal required
ref 82.22 [3.237] I.D.
x 2.62 [0.103] cross section
1.956
[0.077]
8.1 ± 0.25
[0.319 ± 0.010]
H2
9 teeth, 16/32 pitch
162 N•m [1430 lbf•in]
329.857 ± 2.0
[12.986 ± 0.079]
314.73 ± 2.0
[12.391 ± 0.079]
– 0
]
– 0
Spline data
Number of teeth : 9
Pitch fraction : 16/32
Pressure angle : 30°
Pitch-∅ : 14.288 [0.5625]
Typ of fit : Fillet root side
per : Ansi B92.1-1996 class 6
