Danfoss H1 Series Technical Information page 55

Technical Information
H1P 115/130 Axial Piston Single Pumps
Installation drawings
© Danfoss | May 2018
M14
2
X3
L2
1. Charge pressure construction port
2. Connector (Deutsch DT04-2P) to be paint free
Ports per ISO 11926-1 description
Port Description
Charge filtration port from/to filter
E， F
Case drain port
L2
Case pressure port
X3
System B gauge port
MB
Charge gauge port, after filtering
M3
Servo / Case gauge port
M5 / M14
Please contact Danfoss representative for specific installation drawings.
MB
1
F
E
M5
1
M3
5
∕ –24
16
P005 933
Size 115/130
1
1 ∕ –12 Ø42
16
max clearance dia for fitting
5
1 ∕ –12; Ø63
16
max clearance dia for fitting
1
1 ∕ –12; Ø41
16
max clearance dia for fitting
9
∕ –18; Ø28
16
max clearance dia for fitting
9
∕ –18; Ø28
16
max clearance dia for fitting
7
∕ –20; Ø21
16
max clearance dia for fitting
BC00000198en-US0901 | 55
