How to Programme
[Info] can be used throughout the SAS to see help
information for various selections, settings, and messages.
The following three applications are included:
2 2
•
Mechanical Brake
•
Conveyor
•
Pump/Fan
The following four field-busses can be selected:
•
Profibus
•
Profinet
•
DeviceNet
•
EthernetIP
NOTE
The start conditions will be ignored while in the wizard.
NOTE
The Smart Setup runs automatically on the first power-up
of the frequency converter or after a reset to factory
settings. If no action is taken, the SAS screen will automat-
ically disappear after 10 min.

2.1.8 Main Menu Mode

Start the Main Menu mode by pressing [Main Menu]. The
read-out shown below appears on the display.
The middle and bottom sections on the display show a list
of parameter groups which can be chosen by toggling [
▼
and [ ] keys.
Illustration 2.14
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the choice of configuration
(1-00 Configuration Mode), some parameters can be
"missing". E.g. open loop hides all the PID parameters, and
other enabled options make more parameter groups
visible.
18
®
VLT AutomationDrive Programmming Guide
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
MG33ME02 - VLT

2.1.9 Parameter Selection

In the Main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
The following parameter groups are accessible:
Group no. Parameter group
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
7-** Controls
8-** Comm. and Options
9-** Profibus
10-** CAN Fieldbus
11-** Reserved Com. 1
12-** Reserved Com. 2
13-** Smart Logic
14-** Special Functions
15-** Drive Information
16-** Data Readouts
17-** Motor Feedb. Option
18-** Data Readouts 2
30-** Special Features
32-** MCO Basic Settings
33-** MCO Adv. Settings
▲
]
34-** MCO Data Readouts
Table 2.4
1 (1)
After selecting a parameter group, choose a parameter by
means of the navigation keys.
The middle section on the display shows the parameter
number and name as well as the selected parameter value.
Illustration 2.15

2.1.10 Changing Data

The procedure for changing data is the same in the Quick
menu and the Main menu mode. Press [OK] to change the
selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.
®
is a registered Danfoss trademark
740RPM 10.64A 1 [1]
0-0 *
Basic Settings
0 -01 Language
[0] English
