Danfoss VLT AutomationDrive FC 300 Series Programming Manual page 186

Parameter Lists
Par. Parameter description
No. #
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-74 Prec. Stop Counter
16-75 Analog In X30/11
16-76 Analog In X30/12
16-77 Analog Out X30/8 [mA]
16-78 Analog Out X45/1 [mA]
16-79 Analog Out X45/3 [mA]
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
16-82 Fieldbus REF 1
16-84 Comm. Option STW
16-85 FC Port CTW 1
16-86 FC Port REF 1
16-87 Bus Readout Alarm/Warning
16-9* Diagnosis Readouts
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Ext. Status Word
Table 4.22
®
VLT AutomationDrive Programmming Guide
Default value
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0.000 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
®
MG33ME02 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
Type
-3 Int16
0 Int16
0 Int32
0 Int32
0 Int32
4 4
0 Int32
0 Int16
0 Int32
0 Int32
0 Uint32
-3 Int32
-3 Int32
-3 Int16
-3 Int16
-3 Int16
0 V2
0 N2
0 V2
0 V2
0 N2
0 Uint16
0 Uint32
0 Uint32
0 Uint32
0 Uint32
0 Uint32
185
