How to Programme
3. Navigation keys and indicator lights (LEDs).
4. Operation keys and indicator lights (LEDs).
2 2
Display line: Status messages displaying icons and numeric
value.
Indicator lights (LEDs)
•
Green LED/On: Indicates if control section is on.
•
Yellow LED/Wrn.: Indicates a warning.
•
Flashing red LED/Alarm: Indicates an alarm.
LCP keys
[Menu] Select one of the following modes:
•
Status
•
Quick Setup
•
Main Menu
1
2
Menu
On
3
Warn.
Alarm
Hand
4
on
Illustration 2.21
20
®
VLT AutomationDrive Programmming Guide
Setup
Quick Main
Status
Setup Menu
OK
Auto
O Reset
on
MG33ME02 - VLT
Status Mode
Displays the status of the frequency converter or the
motor.
If an alarm occurs the NLCP automatically switches to
status mode.
A number of alarms can be displayed.
NOTE
Parameter copy is not possible with LCP 101 Numerical
Local Control Panel.
Illustration 2.22
A 17
Illustration 2.23
Main Menu/Quick Setup is used for programming all
parameters or only the parameters in the Quick Menu (see
also description of the LCP 102 earlier in ).
The parameter values can be changed by pressing [
▼
[ ] when the value is flashing.
Select Main Menu by pressing [Menu] a number of times.
Select the parameter group [xx-__] and press [OK]
Select the parameter [__-xx] and press [OK]
If the parameter is an array parameter select the array
number and press [OK]
Select the wanted data value and press [OK]
Parameters with functional choices display values such as
[1], [2], etc. For a description of the different choices, see
the individual description of the parameters in 3 Parameter
Descriptions
[Back] for stepping backwards
▲ ▼
[ ] [ ] are used for manoeuvring between commands and
within parameters.
®
is a registered Danfoss trademark
22.8
Setup 1
Setup 1
▲
rpm
] or
