Parameter Descriptions
13-10 Comparator Operand
Array [6]
Option: Function:
[13] Analog input [13] Analog input AI54 Expressed as a
AI54 percentage.
[14] Analog input [14] Analog input AIFB10 [V]. AIFB10 is
AIFB10 internal 10 V supply.
[15] Analog input [15] Analog input AIS24V [V] Analog
AIS24V input AICCT [17] [°]. AIS24V is switch
mode power supply: SMPS 24V.
[17] Analog input [17] Analog input AICCT [°]. AICCT is
AICCT control card temperature.
[18] Pulse input FI29 [18] Pulse input FI29 Expressed as a
percentage.
[19] Pulse input FI33 [19] Pulse input FI33 Expressed as a
percentage.
[20] Alarm number [20] Alarm number The error number.
[21] Warning number
[22] Analog input
x30 11
[23] Analog input
x30 12
[30] Counter A [30] Counter A Number of counts
[31] Counter B [31] Counter B Number of counts
[50] FALSE [50] False Enters the fixed value of false
in the comparator.
[51] TRUE [51] True Enters the fixed value of true
in the comparator.
[52] Control ready [52] Control ready The control board
receives supply voltage
[53] Drive ready [53] Drive ready The frequency converter
is ready for operation and applies a
supply signal on the control board.
[54] Running [54] Running The motor is running.
[55] Reversing [55] Reversing The output is high when
the frequency converter is running
counter clockwise (the logical product of
the status bits "running" AND "reverse")
[56] In range [56] In range The motor is running
within the programmed current and
speed ranges set in 4-50 Warning
Current Low to 4-53 Warning Speed High.
[60] On reference [60] On reference The motor is running
on reference.
[61] Below reference, [61] Below reference, low The motor is
low running below the value given in
4-54 Warning Reference Low
®
VLT AutomationDrive Programmming Guide
13-10 Comparator Operand
Array [6]
Option:
[62]
[65]
[66]
[67]
[68]
[69]
[70]
[71]
[72]
[75]
[76]
[77]
[80]
[82]
[85]
[86]
®
MG33ME02 - VLT is a registered Danfoss trademark
Function:
Above ref, high [62] Above reference, high The motor is
running above the value given in
4-55 Warning Reference High
Torque limit [65] Torque limit The torque limit, set in
4-16 Torque Limit Motor Mode or
4-17 Torque Limit Generator Mode, has
been exceeded.
Current limit [66] Current limit The motor current
limit, set in 4-18 Current Limit, has been
exceeded.
Out of current [67] Out of current range The motor
range current is outside the range set in
4-18 Current Limit.
Below I low [68] Below I low The motor current is
lower than set in 4-50 Warning Current
Low.
Above I high [69] Above I high The motor current is
higher than set in 4-51 Warning Current
High.
Out of speed [70] Out of speed range The speed is
range outside the range set in 4-52 Warning
Speed Low and 4-53 Warning Speed High.
Below speed low [71] Below speed low The output speed
is lower than the setting in
4-52 Warning Speed Low.
Above speed [72] Above speed high The output speed
high is higher than the setting in
4-53 Warning Speed High.
Out of feedb. [75] Out of feedb. Range The feedback is
range outside the range set in 4-56 Warning
Feedback Low and 4-57 Warning
Feedback High.
Below feedb. [76] Below feedb. Low The feedback is
low below the limit set in 4-56 Warning
Feedback Low.
Above feedb. [77] Above feedb. High The feedback is
high above the limit set in 4-57 Warning
Feedback High.
Thermal warning [80] Thermal warning The thermal
warning turns on when the temperature
exceeds the limit in the motor, the
frequency converter, the brake resistor
or thermistor.
Mains out of [82] Mains out of range The mains
range voltage is outside the specified voltage
range.
Warning [85] Warning A warning is active.
Alarm (trip) [86] Alarm (trip) A (trip) alarm is active.
