Parameter Descriptions
1-21 Motor Power [HP]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in HP
related 3000.00 hp] according to the motor nameplate
*
data. The default value corresponds
to the nominal rated output of the
unit. This parameter is visible in LCP if
0-03 Regional Settings is [1] US
1-22 Motor Voltage
Range: Function:
Size related [ 10. - 1000. Enter the nominal motor voltage
*
V] according to the motor nameplate
data. The default value corresponds
to the nominal rated output of the
unit.
1-23 Motor Frequency
Range: Function:
Size [20 - Min - Max motor frequency: 20-1000 Hz.
related 1000 Select the motor frequency value from the
*
Hz] motor nameplate data. If a value different
from 50 Hz or 60 Hz is selected, it is
necessary to adapt the load independent
settings in 1-50 Motor Magnetisation at Zero
Speed to 1-53 Model Shift Frequency. For 87
Hz operation with 230/400 V motors, set the
nameplate data for 230 V/50 Hz. Adapt
4-13 Motor Speed High Limit [RPM] and
3-03 Maximum Reference to the 87 Hz
application.
1-24 Motor Current
Range:
Size related [ 0.10 -
*
10000.00 A]
1-25 Motor Nominal Speed
Range: Function:
Size related [10 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. The data are used for
calculating motor compensations.
n
m,n
1-26 Motor Cont. Rated Torque
Range: Function:
Size [0.1 - Enter the value from the motor
related 10000.0 Nm] nameplate data. The default value
*
corresponds to the nominal rated
output. This parameter is available
when 1-10 Motor Construction is set to
®
VLT AutomationDrive Programmming Guide
Function:
Enter the nominal motor current
value from the motor nameplate
data. The data are used for
calculating torque, motor
protection etc.
= n - n .
s slip
®
MG33ME02 - VLT is a registered Danfoss trademark
1-26 Motor Cont. Rated Torque
Range: Function:
[1] PM, non salient SPM, i.e. the
parameter is valid for PM and non-
salient SPM motors only.
1-29 Automatic Motor Adaptation (AMA)
Option: Function:
The AMA function optimises dynamic motor
performance by automatically optimising the
advanced motor parameters (1-30 Stator
Resistance (Rs) to 1-35 Main Reactance (Xh)) at
motor standstill.
Activate the AMA function by pressing [Hand
on] after selecting [1] or [2]. See also the
section Automatic Motor Adaptation in the
Design Guide. After a normal sequence, the
display will read: "Press [OK] to finish AMA".
After pressing the [OK] key the frequency
converter is ready for operation.
[0] Off
*
[1] Enable Performs AMA of the stator resistance R
complete
rotor resistance R
AMA
X , the rotor leakage reactance X
1
main reactance X
an LC filter is used between the frequency
converter and the motor.
FC 301: The Complete AMA does not include
X measurement for FC 301. Instead, the X
h
value is determined from the motor database.
R is the best adjustment method (see 1-3*
S
Adv. Motor Data).
T4/T5 E and F Frames, T7 D, E and F Frames
will only run a Reduced AMA when the
complete AMA is selected. It is recommended
to obtain the Advanced Motor Data from the
motor manufacturer to enter into 1-31 Rotor
Resistance (Rr) through 1-36 Iron Loss Resistance
(Rfe) for best performance.
[2] Enable Performs a reduced AMA of the stator
reduced resistance R
s
AMA
Note:
•
For the best adaptation of the frequency
converter, run AMA on a cold motor.
•
AMA cannot be performed while the motor is
running.
•
AMA cannot be performed on permanent magnet
motors.
, the
S
, the stator leakage reactance
r
and the
2
. Do not select this option if
h
h
in the system only.
37
3 3
