Danfoss VLT AutomationDrive FC 300 Series Programming Manual page 129

Parameter Descriptions
13-52 SL Controller Action
Array [20]
Option:
[23] Run reverse
3 3
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
[38] Set digital out
A high
[39] Set digital out
B high
[40] Set digital out
C high
[41] Set digital out
D high
[42] Set digital out
E high
[43] Set digital out
F high
128
®
VLT AutomationDrive Programmming Guide
Function:
[23] Run reverse - issues a start reverse
command to the frequency converter.
[24] Stop - issues a stop command to the
frequency converter.
[25] Qstop - issues a quick stop command
to the frequency converter.
[26] Dcstop - issues a DC stop command to
the frequency converter.
[27] Coast - the frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
[28] Freeze output - freezes the output
frequency of the frequency converter.
[29] Start timer 0 - starts timer 0, see
13-20 SL Controller Timer for further
description.
[30] Start timer 1 - starts timer 1, see
13-20 SL Controller Timer for further
description.
[31] Start timer 2 - starts timer 2, see
13-20 SL Controller Timer for further
description.
[32] Set digital output A low - any output
with SL output A will be low.
[33] Set digital output B low - any output
with SL output B will be low.
[34] Set digital output C low - any output
with SL output Cwill be low.
[35] Set digital output D low - any output
with SL output D will be low.
[36] Set digital output E low - any output
with SL output E will be low.
[37] Set digital output F low - any output
with SL output F will be low.
[38] Set digital output A high - any output
with SL output A will be high.
[39] Set digital output B high - any output
with SL output B will be high.
[40] Set digital output C high - any output
with SL output C will be high.
[41] Set digital output D high - any output
with SL output D will be high.
[42] Set digital output E high - any output
with SL output E will be high.
[43] Set digital output F high - any output
with SL output Fwill be high.
MG33ME02 - VLT
13-52 SL Controller Action
Array [20]
Option:
[60] Reset Counter
A
[61] Reset Counter
B
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7
®
is a registered Danfoss trademark
Function:
[60] Reset Counter A - resets Counter A to
zero.
[61] Reset Counter B - resets Counter B to
zero.
[70] Start Timer 3 - Start Timer 3, see
13-20 SL Controller Timer for further
description.
[71] Start Timer 4 - Start Timer 4, see
13-20 SL Controller Timer for further
description.
[72] Start Timer 5 - Start Timer 5, see
13-20 SL Controller Timer for further
description.
[73] Start Timer 6 - Start Timer 6, see
13-20 SL Controller Timer for further
description.
[74] Start Timer 7 - Start Timer 7, see
p13-20 SL Controller Timer for further
description.
