Danfoss VLT AutomationDrive FC 300 Series Programming Manual page 187

Parameter Lists
4.1.19 17-** Motor Feedb.Option
Par. Parameter description
No. #
17-1* Inc. Enc. Interface
17-10 Signal Type
17-11 Resolution (PPR)
4 4
17-2* Abs. Enc. Interface
17-20 Protocol Selection
17-21 Resolution (Positions/Rev)
17-24 SSI Data Length
17-25 Clock Rate
17-26 SSI Data Format
17-34 HIPERFACE Baudrate
17-5* Resolver Interface
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
17-6* Monitoring and App.
17-60 Feedback Direction
17-61 Feedback Signal Monitoring
Table 4.23
186
®
VLT AutomationDrive Programmming Guide
Default value
[1] RS422 (5V TTL)
1024 N/A
[0] None
App.Dependent
13 N/A
App.Dependent
[0] Gray code
[4] 9600
2 N/A
7.0 V
10.0 kHz
0.5 N/A
[0] Disabled
[0] Disabled
[0] Clockwise
[1] Warning
®
MG33ME02 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
Type
- Uint8
0 Uint16
- Uint8
0 Uint32
0 Uint8
3 Uint16
- Uint8
- Uint8
0 Uint8
-1 Uint8
2 Uint8
-1 Uint8
- Uint8
- Uint8
- Uint8
- Uint8
