Danfoss VLT AutomationDrive FC 300 Series Programming Manual page 111

Parameter Descriptions
8-50 Coasting Select
Option:
[2] Logic AND
3 3
[3] Logic OR
*
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
(digital input) and/or via the bus.
Option:
[0]
[1]
[2]
[3]
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates Start command via the fieldbus/serial
[3] Logic OR
*
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates Start command via the fieldbus/serial
110
VLT
Function:
Activates Start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTE
Only selection [0] Digital input is available
when 1-10 Motor Construction is set to [1]
PM non-salient SPM.
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
communication port, AND additionally via one
of the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates Start command via a digital input.
Activates Start command via the serial
communication port or fieldbus option.
communication port, AND additionally via one
of the digital inputs.
MG33ME02 - VLT
®
AutomationDrive Programmming Guide
8-53 Start Select
Option:
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-55 Set-up Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates the set-up selection via the fieldbus/
[3] Logic OR
*
8-56 Preset Reference Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND Activates Preset Reference selection via the
[3] Logic OR
*
®
is a registered Danfoss trademark
Function:
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter
reverse function via the terminals (digital
input) and/or via the fieldbus.
Activates the Reverse command via the serial
communication port or fieldbus option.
Activates the Reverse command via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Activates the Reverse command via the
fieldbus/serial communication port OR via one
of the digital inputs.
Function:
Select control of the frequency converter set-
up selection via the terminals (digital input)
and/or via the fieldbus.
Activates the set-up selection via a digital
input.
Activates the set-up selection via the serial
communication port or fieldbus option.
serial communication port, AND additionally
via one of the digital inputs.
Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
Function:
Select control of the frequency converter
Preset Reference selection via the terminals
(digital input) and/or via the fieldbus.
Activates Preset Reference selection via a
digital input.
Activates Preset Reference selection via the
serial communication port or fieldbus option.
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Activates the Preset Reference selection via the
fieldbus/serial communication port OR via one
of the digital inputs.
