Parameter Descriptions
13-42 Logic Rule Boolean 2
Array [6]
Option:
[22] Comparator 0
[23] Comparator 1
3 3
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
124
®
VLT AutomationDrive Programmming Guide
Function:
Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If
the alarm 164 ATEX ETR
®
MG33ME02 - VLT is a registered Danfoss trademark
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
cur.lim.alarm is active, the output
will be 1.
[91] ATEX ETR cur. alarm Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If
the alarm 166 ATEX ETR
freq.lim.alarm is active, the output
will be 1.
[92] ATEX ETR freq. warning Selectable if1-90 Motor Thermal
Protection is set to [20] or [21] ]. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the
output will be 1.
[93] ATEX ETR freq. alarm Selectable if 1-90 Motor Thermal
Protection is set to [20] or [21]. If
the warning 165 ATEX ETR
freq.lim.warning is active, the
output will be 1.
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
13-43 Logic Rule Operator 2
Array [6]
Option: Function:
Select the second logical operator to be
used on the boolean input calculated in
13-40 Logic Rule Boolean 1, 13-41 Logic Rule
Operator 1, and 13-42 Logic Rule Boolean 2,
and the boolean input coming from
13-42 Logic Rule Boolean 2.
[13-44] signifies the boolean input of
13-44 Logic Rule Boolean 3.
[13-40/13-42] signifies the boolean input
calculated in 13-40 Logic Rule Boolean 1,
13-41 Logic Rule Operator 1, and 13-42 Logic
Rule Boolean 2. [0] DISABLED (factory
setting). select this option to ignore
13-44 Logic Rule Boolean 3.
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
