5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
Relay Bus Control. In the event of bus
time-out the output state is set low
(Off).
[51] MCO controlled Active when a MCO 302 or MCO 305
is connected. The output is
controlled from option.
[60] Comparator 0 See parameter group 13-1* (Smart
Logic Control). If Comparator 0 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[61] Comparator 1 See parameter group 13-1* (Smart
Logic Control). If Comparator 1 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[62] Comparator 2 See parameter group 13-1* (Smart
Logic Control). If Comparator 2 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[63] Comparator 3 See parameter group 13-1* (Smart
Logic Control). If Comparator 3 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[64] Comparator 4 See parameter group 13-1* (Smart
Logic Control). If Comparator 4 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[65] Comparator 5 See parameter group 13-1* (Smart
Logic Control). If Comparator 5 in
SLC is TRUE, the output will go high.
Otherwise, it will be low.
[70] Logic rule 0 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 0 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[71] Logic rule 1 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 1 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[72] Logic rule 2 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 2 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[73] Logic rule 3 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 3 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
®
VLT AutomationDrive Programmming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[74]
[75]
[80]
[81]
[82]
[83]
[84]
[85]
[120] Local ref active
®
MG33ME02 - VLT is a registered Danfoss trademark
Function:
Logic rule 4 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 4 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 5 See parameter group 13-4* (Smart
Logic Control). If Logic Rule 5 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
SL digital output A See 13-52 SL Controller Action.
Output A is low on Smart Logic
Action [32]. Output A is high on
Smart Logic Action [38].
SL digital output B See 13-52 SL Controller Action.
Output B is low on Smart Logic
Action [33]. Output B is high on
Smart Logic Action [39].
SL digital output C See 13-52 SL Controller Action.
Output C is low on Smart Logic
Action [34]. Output C is high on
Smart Logic Action [40].
SL digital output D See 13-52 SL Controller Action.
Output D is low on Smart Logic
Action [35]. Output D is high on
Smart Logic Action [41]
SL digital output E See 13-52 SL Controller Action.
Output E is low on Smart Logic
Action [36]. Output E is high on
Smart Logic Action [42].
SL digital output F See 13-52 SL Controller Action.
Output F is low on Smart Logic
Action [37]. Output F is high on
Smart Logic Action [43].
Output is high when 3-13 Reference
Site = [2] Local or when
3-13 Reference Site = [0] Linked to
hand auto at the same time as the
LCP is in [Hand on] mode.
